Motorola APX 2000 Detailed Service Manual

Troubleshooting Tables: List of Board and IC Signals 7-41
Test Place
Front Kit Flex
Signal Name Pin #
GND P1-1
F_DISP_RW P1-2
PTT P1-3
F_DISP_DATA_0 P1-4
SIDE_1 P1-5
F_DISP_DATA_1 P1-6
SIDE_2 P1-7
F_DISP_DATA_2 P1-8
MONITOR P1-9
F_DISP_DATA_3 P1-10
GND P1-11
F_DISP_DATA_4 P1-12
GPIO_3_RTS_FILLSENSE P1-13
F_DISP_DATA_5 P1-14
GPIO_2_DM_RXDC_FILLDATA P1-15
F_DISP_DATA_6 P1-16
GPIO_1_DP_TXDC_FILLREQ P1-17
F_DISP_DATA_7 P1-18
GCAI_1WIRE_5V P1-19
GND P1-20
GPIO_4_CTS_KEYFAIL_FILLCL
K
P1-21
F_DISP_RW_EN P1-22
VBUS2 P1-23
GND P1-24
VBUS2 P1-25
F_DISP_DATA_CMD P1-26
GPIO_0 P1-27
V_2.775D P1-28
EXT_MIC_NEG_DP P1-29
OMAP_RESET P1-30

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
