Motorola APX 2000 Detailed Service Manual

7-42 Troubleshooting Tables: List of Board and IC Signals
EXT_MIC_POS_DP P1-31
MAIN_DISPLAY_LED1 P1-32
EXT_SPKR_POS_DP P1-33
MAIN_DISPLAY_LED2 P1-34
EXT_SPKR_NEG_DP P1-35
MAIN_DISPLAY_LED3 P1-36
GND P1-37
MAIN_DISPLAY_LED4 P1-38
SPKR+ P1-39
F_DISP_BD_ID P1-40
LS1 SPKR+ P1-41
GND P1-42
LS1 SPKR- P1-43
C3 FREQ_SEL_0 P1-44
SPKR- P1-45
C4 FREQ_SEL_1 P1-46
MIC+ P1-47
C6 FREQ_SEL_2 P1-48
MIC- P1-49
C5 FREQ_SEL_3 P1-50
GND P1-51
VCC_1.85 P1-52
SPEAKER_RED_1 P1-53
NFC P1-54
SPEAKER_GREEN_1 P1-55
GND P1-56
SPEAKER_AMBER_1 P1-57
TX_RX_LED_AMBER P1-58
SW_5+ P1-59
TX_RX_LED_RED P1-60
GND P1-61
Test Place
Front Kit Flex
Signal Name Pin #
