Motorola APX 2000 Detailed Service Manual

8-68 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: VHF (84012320001 / PC000352A01)
VHF Transceiver (RF) Board Parts List –
84012320001
Ref. Des. Part Number Description
C101M12 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1101M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1102M11 2188468Y01 CAP CER 25V X7R 0805
1UF
C1103M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1104M11 NOTPLACED 64AM DUMMY PART
NUMBER
C1105M11 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C1106M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1107M11 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1108M11 2113945B06 CAP,FXD,.047UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C1110M11 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C1111M11 211394 5Y02 CAP,FXD, .1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1112M11 2113945B01 CAP CER CHP 6800PF 25V
10%
C1113M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1116M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1117M11 2113945A12 CAP CER CHP 3300PF 50V
10%
C1118M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1119M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1120M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1122M11 2113944M04 CAP,FXD,2.7PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1123M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1124M11 2113945A13 CAP CER CHP 4700PF 50V
10%
C1125M11 2113944A23 CAP CER CHP 8.2PF 50V
+/- 0.5PF
C1126M11 2113945A09 CAP CER CHP 1000PF 50V
10%
C1127M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1128M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1129M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1130M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1135M11 NOTPLACED 64AM DUMMY PART
NUMBER
C1137M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1138M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1139M11 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5PF
C1140M11 2113945A13 CAP CER CHP 4700PF 50V
10%
C1141M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1142M11 2113945A09 CAP CER CHP 1000PF 50V
10%
C1155M11 NOTPLACED 64AM DUMMY PART
NUMBER
Ref. Des. Part Number Description
C1160M11 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C1161M11 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C1165M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1203M17 2113944M12 CAP,FXD,5.6PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1204M17 2113944M09 CAP,FXD,4.3PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1207M17 2113944M28 CAP,FXD,27PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1220M17 2113944M16 CAP,FXD,8.2PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1221M17 2113944M27 CAP,FXD,24PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1222M17 2113944C04 CAP CER CHP 330.0PF
50V 5%
C1226M17 2175662M26 CAPACITOR 4.3 ?0.1PF,
CERAMIC, 100V
C1227M17 2113944M17 CAP,FXD,9.1PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1301M3 2172180Y01 CAP,CHIP,2.2UF,+20%,-
20%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
C1302M3 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C1303M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
Ref. Des. Part Number Description
C1304M3 2113944A26 CAP CER CHP 12.0PF 50V
5%
C1305M3 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1306M3 2187893N01 CAP 1UF, 6.3V, X5R, 0402
PACKAG E
C1307M3 2113944A26 CAP CER CHP 12.0PF 50V
5%
C1308M3 2113945A09 CAP CER CHP 1000PF 50V
10%
C1309M3 2113944A26 CAP CER CHP 12.0PF 50V
5%
C1310M3 2187893N01 CAP 1UF, 6.3V, X5R, 0402
PACKAG E
C1311M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
C1312M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
C1313M3 2187893N01 CAP 1UF, 6.3V, X5R, 0402
PACKAG E
C1314M3 2113944M20 CAP,FXD,12PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1315M3 2175389H01 CAP,.5PF, CHIP, 0402,
CERAMIC, 50 V
C1317M3 2188881Y12 CAPACITOR CERAMIC
NPO HIGH FREQUENCY
16 VOLT (REPLACES
2104801Z12)
C1318M3 2113944A13 CAP CER CHP 3.3PF 50V
+/- 0.25PF
C1319M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1320M3 2113944A28 CAP CER CHP 18.0PF 50V
5%
C1321M3 2113944A29 CAP CER CHP 22.0PF 50V
5%
Ref. Des. Part Number Description
