Motorola APX 2000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: VHF (84012320001 / PC000352A01) 8-69
C1322M3 2113944A29 CAP CER CHP 22.0PF 50V
5%
C1323M3 2113944A29 CAP CER CHP 22.0PF 50V
5%
C1324M3 2115153H03 CAP, CERAMIC, COG
C1325M3 2113944A29 CAP CER CHP 22.0PF 50V
5%
C1326M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1327M3 2113944A28 CAP CER CHP 18.0PF 50V
5%
C1328M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1329M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1330M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1331M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1332M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1333M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1334M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1335M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
C1336M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1337M3 2113944A28 CAP CER CHP 18.0PF 50V
5%
C1376M3 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5PF
C200M12 2113945B02 CAP CER CHP 10,000PF
25V 10%
C201M12 2188468Y01 CAP CER 25V X7R 0805
1UF
C202M12 2188468Y01 CAP CER 25V X7R 0805
1UF
C203M12 2188468Y01 CAP CER 25V X7R 0805
1UF
C204M12 2113955D35 CAP,FXD,4.7UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C205M12 2113955D35 CAP,FXD,4.7UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C206M12 2113945B02 CAP CER CHP 10,000PF
25V 10%
C207M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C208M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C209M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C21000M2 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C21001M2 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
C21002M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C21003M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C21004M2 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C21005M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2104M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C210M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C2114M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2115M2 2113944A40 CAP CER CHP 100.0PF
50V 5%
C2116M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2126M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C2127M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C2128M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C2129M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C212M12 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C2130M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C213M12 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C214M12 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C215M12 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C216M12 2113944A46 CAP CER CHP 330.0 PF
50V 5%
Ref. Des. Part Number Description
C217M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C2201M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2202M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2203M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2211M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2212M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2213M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2214M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2215M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2216M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2221M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2222M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2223M2 2113944A40 CAP CER CHP 100.0PF
50V 5%
C2401M2 NOTPLACED 64AM DUMMY PART
NUMBER
C2402M2 NOTPLACED 64AM DUMMY PART
NUMBER
C2403M2 NOTPLACED 64AM DUMMY PART
NUMBER
C2404M2 NOTPLACED 64AM DUMMY PART
NUMBER
C2701M13 2113944C04 CAP CER CHP 330.0PF
50V 5%
C2702M13 2113944C48 CAP CER CHP 560.OPF
50V 5%
C2703M13 2113944A46 CAP CER CHP 330.0 PF
50V 5%
Ref. Des. Part Number Description
