8-94 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: VHF (84012320001 / PC000352A01)

C754M7 2113944A34 CAP,CHIP,56PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C756M7 2113955D37 CAP,FXD,10UF,+10%,-

10%,16V-DC,1206,X7R,-

55DEG CMIN,125DEG

CMAX

C757M7 2113945C31 CAP,FXD,.1UF,+10%,-

10%,50V-DC,0603,X7R,-

55DEG CMIN,125DEG

CMAX

C760M7 2113944A44 CAP,CHIP,220PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C764M7 2113946B06 CAP,CHIP,.22UF,+10%,-

10%,10V-DC,0402,X5R,-

55DEG CMIN,85DEG CMAX

C768M7 2113944A25 CAP,CHIP,10PF,.5PF+/-

,50V-DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C770M7 2113944A44 CAP,CHIP,220PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C772M7 2113945A09 CAP,CHIP,1000PF,+10%,-

10%,50V-DC,0402,X7R,-

55DEG CMIN,125DEG CM

C773M7 2113944A33 CAP,CHIP,47PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C777M7 2113944A44 CAP,CHIP,220PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C780M7 2113944A33 CAP,CHIP,47PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C781M7 2113944A44 CAP,CHIP,220PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

Ref. Des. Part Number Description

C786M7 2113944A44 CAP,CHIP,220PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C803M7 2113944A44 CAP,CHIP,220PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C813M7 2113944A13 CAP,CHIP,3.3PF,.25PF+/-

,50V-DC,0402,C0G,-55DEG

CMIN,125DEG CMA

C816M7 2113944A35 CAP,CHIP,62PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C817M7 2113944A44 CAP,CHIP,220PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C819M7 2113944A44 CAP,CHIP,220PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C823M7 2113944A40 CAP,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C824M7 2113944A44 CAP,CHIP,220PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C901M16 2113944M49 CAP,FXD,1000PF,+1%,-

1%,50V-DC,C0G,-55DEG

CMIN,125DEG CMAX,PB-F

C902M16 2113944C04 CAP,CHIP,330PF,+5%,-

5%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX

C903M16 2113945L49 CAP,FXD,.01UF,+5%,-

5%,50V-DC,0603,X7R,-

55DEG CMIN,125DEG

CMAX,P

C904M16 2113944M36 CAP,FXD,56PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

Ref. Des. Part Number Description

C905M16 2113945L49 CAP,FXD,.01UF,+5%,-

5%,50V-DC,0603,X7R,-

55DEG CMIN,125DEG

CMAX,P

C906M16 2113944C04 CAP,CHIP,330PF,+5%,-

5%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX

C907M16 2113944C04 CAP,CHIP,330PF,+5%,-

5%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX

C908M16 2113944C04 CAP,CHIP,330PF,+5%,-

5%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX

C909M16 2113944C04 CAP,CHIP,330PF,+5%,-

5%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX

C910M16 NOTPLACED 64AM DUMMY PART NUM-

BER

C911M16 2113945L49 CAP,FXD,.01UF,+5%,-

5%,50V-DC,0603,X7R,-

55DEG CMIN,125DEG

CMAX,P

C912M16 NOTPLACED 64AM DUMMY PART NUM-

BER

C913M16 2113944M34 CAP,FXD,47PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C914M16 2113944M34 CAP,FXD,47PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C915M16 2113944C04 CAP,CHIP,330PF,+5%,-

5%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX

C916M16 2113944M42 CAP,FXD,100PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,P

C917M16 NOTPLACED 64AM DUMMY PART NUM-

BER

Ref. Des. Part Number Description

C918M16 2113944C48 CAP,CHIP,560PF,+5%,-

5%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX

C919M16 2113944M22 CAP,FXD,15PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C920M16 21009257002 CAP,CER,39PF,+5%,-

5%,50V-DC,0805,-55DEG

CMIN,125DEG CMAX,0805

C921M16 21009257002 CAP,CER,39PF,+5%,-

5%,50V-DC,0805,-55DEG

CMIN,125DEG CMAX,0805

C922M16 2113944M28 CAP,FXD,27PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C923M16 NOTPLACED 64AM DUMMY PART NUM-

BER

C924M16 2113944M22 CAP,FXD,15PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C925M16 2113944C04 CAP,CHIP,330PF,+5%,-

5%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX

C927M16 NOTPLACED 64AM DUMMY PART NUM-

BER

C928M16 2113944M22 CAP,FXD,15PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C929M16 2113945A12 CAP,CHIP,3300PF,+10%,-

10%,50V-DC,0402,X7R,-

55DEG CMIN,125DEG CM

C930M16 2113945A12 CAP,CHIP,3300PF,+10%,-

10%,50V-DC,0402,X7R,-

55DEG CMIN,125DEG CM

D200M12 4813978A19 DIODE,RECT,MBR120,SM,

SOD-123,1A,20V,SHTK,PB-

FREE

Ref. Des. Part Number Description

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
