Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: VHF (84012320001 / PC000352A01) 8-95
D2701M13 4813974A19 DIODE
ARRAY,MXR,SM,SOT-
323,7V,.2W,SHTK,2,PB-
FREE
D2702M13 4815897H01 DIODE,PIN,UPP9401E,SM,
DO-
216,50A,50V,2.5W,POWER-
MITE
D2703M13 4815897H01 DIODE,PIN,UPP9401E,SM,
DO-
216,50A,50V,2.5W,POWER-
MITE
D301M20 NOTPLACED 64AM DUMMY PART NUM-
BER
D3206M22 4815002H03 DIODE,VCTR,SM,DIODE,V
CTR, 34V,SILICON EPITAX-
IAL
D3207M22 4815002H03 DIODE,VCTR,SM,DIODE,V
CTR, 34V,SILICON EPITAX-
IAL
D3208M22 4815002H03 DIODE,VCTR,SM,DIODE,V
CTR, 34V,SILICON EPITAX-
IAL
D3209M22 4815002H03 DIODE,VCTR,SM,DIODE,V
CTR, 34V,SILICON EPITAX-
IAL
D3246M22 4815002H03 DIODE,VCTR,SM,DIODE,V
CTR, 34V,SILICON EPITAX-
IAL
D3247M22 4815002H03 DIODE,VCTR,SM,DIODE,V
CTR, 34V,SILICON EPITAX-
IAL
D3248M22 4815002H03 DIODE,VCTR,SM,DIODE,V
CTR, 34V,SILICON EPITAX-
IAL
D3249M22 4815002H03 DIODE,VCTR,SM,DIODE,V
CTR, 34V,SILICON EPITAX-
IAL
D4001M2 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,P
B-FREE, W18
D6101M6 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,P
B-FREE, W18
Ref. Des. Part Number Description
D6401M6 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,P
B-FREE, W18
D6501M6 4813978A25 DIODE,SWG,BAT54,SM,SO
D-323/SC-
76,200MA,30V,.2W,SHTK,P
B-FREE, W18
D722M7 4815011H01 DIODE,SWG,SM,300MA,80
V,T RP
D723M7 4815011H01 DIODE,SWG,SM,300MA,80
V,T RP
E1101M11 2405688Z01 IDCTR,BEAD,FERR BEAD
E201M12 7686949J14 FLTR,FERRITE
BEAD,2A,SM,0805,CHIP,22
0OHM
E2242M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2244M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2245M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2246M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2247M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2248M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2249M2 7685268E01 FLTR,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2301M2 7688697V03 FLTR,EMI/
RFI,500MA,SM,0402,PB
FREE
E2302M2 7688697V03 FLTR,EMI/
RFI,500MA,SM,0402,PB
FREE
Ref. Des. Part Number Description
E2303M2 7688697V03 FLTR,EMI/
RFI,500MA,SM,0402,PB
FREE
E2304M2 7688697V03 FLTR,EMI/
RFI,500MA,SM,0402,PB
FREE
E2305M2 7688697V03 FLTR,EMI/
RFI,500MA,SM,0402,PB
FREE
E2306M2 7688697V03 FLTR,EMI/
RFI,500MA,SM,0402,PB
FREE
E2307M2 7688697V03 FLTR,EMI/
RFI,500MA,SM,0402,PB
FREE
E2308M2 7688697V03 FLTR,EMI/
RFI,500MA,SM,0402,PB
FREE
E2309M2 7688697V03 FLTR,EMI/
RFI,500MA,SM,0402,PB
FREE
E2310M2 7688697V03 FLTR,EMI/
RFI,500MA,SM,0402,PB
FREE
E2311M2 7688697V03 FLTR,EMI/
RFI,500MA,SM,0402,PB
FREE
E302M20 2480640Z01 CHIP INDUC-
TOR,BEAD,SUR MT FERR
BEAD
E601M19 2480640Z01 CHIP INDUC-
TOR,BEAD,SUR MT FERR
BEAD
E602M19 2480640Z01 CHIP INDUC-
TOR,BEAD,SUR MT FERR
BEAD
E603M19 2480640Z01 CHIP INDUC-
TOR,BEAD,SUR MT FERR
BEAD
E604M19 2480640Z01 CHIP INDUC-
TOR,BEAD,SUR MT FERR
BEAD
E605M19 2480640Z01 CHIP INDUC-
TOR,BEAD,SUR MT FERR
BEAD
Ref. Des. Part Number Description
E606M19 2480640Z01 CHIP INDUC-
TOR,BEAD,SUR MT FERR
BEAD
E607M19 2480640Z01 CHIP INDUC-
TOR,BEAD,SUR MT FERR
BEAD
E608M19 2480640Z01 CHIP INDUC-
TOR,BEAD,SUR MT FERR
BEAD
E609M19 2480640Z01 CHIP INDUC-
TOR,BEAD,SUR MT FERR
BEAD
E6501M6 2480067M02 FIXED INDUC-
TOR,FXD,200MA,.4OHM,F
ERR,0805,CHK RF CHIP
BE
E6502M6 2480067M02 FIXED INDUC-
TOR,FXD,200MA,.4OHM,F
ERR,0805,CHK RF CHIP
BE
F200M12 6575834B01 FUSE,FST
BLW,2A,32V,FUSE SUR MT
FL1301M3 9102190J23 FLTR,SAW,BAND-
PASS,1.57542GHZ
NOM,SM,1.4X1.0MM,SMD,
PB-FREE
FL1302M3 9109674L58 BAND PASS FILTER
FL1303M3 9102190J23 FLTR,SAW,BAND-
PASS,1.57542GHZ
NOM,SM,1.4X1.0MM,SMD,
PB-FREE
FL502M21 91009300001 FLTR,BAND-
PASS,109.65MHZ NOM,FIL-
TER,MONOLITHIC
CRYSTAL,BAND
J102M12 2880658Z08 RF CONNEC-
TOR,SMA,M,CONN SMA
J2301M2 0970312N01 CONN,BTB,RCPT,60CONT,.
4MM,GLD,1 STACK HGT
J2302M2 CN000222A0
1
CONNECTOR STANDARD-
BTB,FEMALE(RECEPTA-
CLE/SOCKET),0.4
MM,70,CONN
L1101M11 2415429H26 IDCTR,WW,33NH,5%,600M
A,.22OHM,CER,SM,0603,C
HIP
Ref. Des. Part Number Description
To Next Page
