8-96 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: VHF (84012320001 / PC000352A01)
L1102M11 2415429H10 IDCTR,WW,6.8NH,5%,700M
A,.11OHM,CER,SM,0603,C
HIP
L1116M11 NOTPLACED 64AM DUMMY PART NUM-
BER
L1117M11 2415428H01 COIL,AW,1.65NH,10%,1.6A,
AIR,2 TURNS,SM,AIR
WOUND IDCTR
L1203M17 2416066H02 IDCTR,COIL,43NH,5%,2A,.
035OHM,50 Q,2GHZ
SRF,IDCTR
L1209M17 2416066H02 IDCTR,COIL,43NH,5%,2A,.
035OHM,50 Q,2GHZ
SRF,IDCTR
L1211M17 2416066H02 IDCTR,COIL,43NH,5%,2A,.
035OHM,50 Q,2GHZ
SRF,IDCTR
L1301M3 2414017P16 IDCTR,CHIP,18NH,5%,300
MA,.76OHM,CER,9
Q,1.9GHZ SRF,SM,0402,P
L1302M3 2488090Y07 IDCTR,CHIP,3.3NH,5%,300
MA,CER,SM,0402,MULAY
PB FREE
L1303M3 2414017P16 IDCTR,CHIP,18NH,5%,300
MA,.76OHM,CER,9
Q,1.9GHZ SRF,SM,0402,P
L1304M3 2488090Y25 IDCTR,CHIP,100NH,5%,90
MA,CER,SM,0402,MULAY
PB FREE
L1305M3 24010062002 IDCTR,RF,5.6NH,2%,1.6A,.
06OHM,CER,6.5GHZ
SRF,SM,5.6NH, 040
L1306M3 2414017P14 IDCTR,CHIP,12NH,5%,300
MA,.6OHM,CER,9 Q,2GHZ
SRF,SM,0402,PB-F
L1308M3 2415429H14 CHIP INDUC-
TOR,9.5NH,5%,700MA
L1316M3 24010062009 IDCTR,RF,13NH,2%,870MA
,.06OHM,CER,4.2GHZ
SRF,SM,13NH, 0402
L200M12 2571269C01 IDCTR,COIL,1.5UH,20%,2.9
A,.059OHM,FERR,SM,WW
PWR W18 COMP
L2202M2 2415429H45 IDCTR,WW,270NH,5%,170
MA,CER,SM,CHIP
Ref. Des. Part Number Description
L2203M2 2415429H45 IDCTR,WW,270NH,5%,170
MA,CER,SM,CHIP
L2204M2 2415429H45 IDCTR,WW,270NH,5%,170
MA,CER,SM,CHIP
L2205M2 2415429H45 IDCTR,WW,270NH,5%,170
MA,CER,SM,CHIP
L2701M13 2416066H02 IDCTR,COIL,43NH,5%,2A,.
035OHM,50 Q,2GHZ
SRF,IDCTR
L2702M13 2415429H40 IDCTR,WW,180NH,5%,240
MA,1.25OHM,CER,SM,0603
,CHIP
L312M20 2414032F35 IDCTR,WW,120NH,5%,400
MA,.51OHM,CER,35
Q,860MHZ SRF,SM,PB-FR
L313M20 2415429H28 IDCTR,WW,39NH,5%,600M
A,CER,SM,CHIP
L314M20 2415429H28 IDCTR,WW,39NH,5%,600M
A,CER,SM,CHIP
L315M20 2414017N22 IDCTR,CHIP,68NH,5%,400
MA,1.2OHM,CER,15
Q,800MHZ SRF,SM,0603
L316M20 2415429H34 IDCTR,WW,72NH,5%,400M
A,.49OHM,CER,SM,0603,C
HIP
L317M20 2414017P13 IDCTR,CHIP,10NH,5%,300
MA,.46OHM,CER,9
Q,2.5GHZ SRF,SM,0402,P
L318M20 2414032F35 IDCTR,WW,120NH,5%,400
MA,.51OHM,CER,35
Q,860MHZ SRF,SM,PB-FR
L319M20 2414032F35 IDCTR,WW,120NH,5%,400
MA,.51OHM,CER,35
Q,860MHZ SRF,SM,PB-FR
L3205M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L320M20 2415429H28 IDCTR,WW,39NH,5%,600M
A,CER,SM,CHIP
L3210M22 2415429H27 IDCTR,WW,36NH,5%,600M
A,.25OHM,CER,SM,0603,C
HIP
Ref. Des. Part Number Description
L3216M22 2415010H04 IDCTR,AW,11.4NH,2%,AIR,
0 AWG,SM,AIRWOUND
COIL
L321M20 2415429H28 IDCTR,WW,39NH,5%,600M
A,CER,SM,CHIP
L3223M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L3229M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L3230M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L3245M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L3250M22 2415429H30 IDCTR,WW,47NH,5%,600M
A,CER,SM,CHIP
L3256M22 2414015C05 IDCTR,FXD,33NH,2%,1.3M
A,.09OHM,CER,75
Q,1.7GHZ SRF,SM,1008,P
L3261M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L3269M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L3270M22 2414032F44 IDCTR,WW,680NH,10%,130
MA,4OHM,CER,30
Q,570MHZ SRF,SM,PB-FRE
L327M20 2414032F35 IDCTR,WW,120NH,5%,400
MA,.51OHM,CER,35
Q,860MHZ SRF,SM,PB-FR
L328M20 0613952G67 RES,MF,0,1,.1,SM,0603,PB-
FREE
L329M20 2478057A30 CHIP INDUC-
TOR,RF,30NH,2%,SM,0603
HI Q CHIP IDCTR
L500M21 2415429H43 IDCTR,WW,220NH,5%,300
MA,2.1OHM,CER,SM,0603,
CHIP
L503M21 2414017N24 IDCTR,CHIP,100NH,5%,300
MA,2OHM,CER,15
Q,700MHZ SRF,SM,0603,P
Ref. Des. Part Number Description
L504M21 2478057A51 CHIP INDUC-
TOR,RF,270NH,2%,SM,060
3 HI Q CHIP IDCTR
L513M21 NOTPLACED 64AM DUMMY PART NUM-
BER
L550M21 2414017N20 IDCTR,CHIP,47NH,5%,500
MA,.86OHM,CER,14
Q,900MHZ SRF,SM,0603
L601M19 2415429H43 IDCTR,WW,220NH,5%,300
MA,2.1OHM,CER,SM,0603,
CHIP
L602M19 2466505A01 CHIP INDUC-
TOR,CHIP,10UH,5%,150MA
,FERR,0 AWG,SM,PB-
FREE
L603M19 2466505A01 CHIP INDUC-
TOR,CHIP,10UH,5%,150MA
,FERR,0 AWG,SM,PB-
FREE
L604M19 2414032D16 IDCTR,WW,120NH,5%,800
MA,.26OHM,CER,42
Q,1GHZ SRF,SM,PB-FREE
L605M19 24012050001 IDCTR,FXD,3.9UH,2%,280
MA,CER,SM,0603LS CHIP
INDUCTORS, 1
L611M19 2414032F39 IDCTR,WW,270NH,10%,280
MA,1OHM,CER,40
Q,800MHZ SRF,SM,PB-FRE
L6401M6 2471189M03 IDCTR,PWR,10UH,20%,1.1
A,.2OHM,SM,SHLD SMT
PWR IDCTR 10UH
L6402M6 2471189M03 IDCTR,PWR,10UH,20%,1.1
A,.2OHM,SM,SHLD SMT
PWR IDCTR 10UH
L6403M6 24009271001 CHK,RF CHOKE,20NH HI
CUR CHIP IDCTR
L6404M6 24009271001 CHK,RF CHOKE,20NH HI
CUR CHIP IDCTR
L6502M6 2471678H01 IDCTR,10UH,20%,FERR,10
UH INDCUTOR
L6504M6 24009268001 IDCTR,PWR,10UH,20%,1.3
A,FERR,SM,10UH 2.1A
SHLD IDCTR
L6505M6 2471678H01 IDCTR,10UH,20%,FERR,10
UH INDCUTOR
Ref. Des. Part Number Description
