Page #353 background imageLoading...
Page #353 background image
Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: VHF (84012320001 / PC000352A01) 8-97
L709M7 2415429H28 IDCTR,WW,39NH,5%,600M
A,CER,SM,CHIP
L720M7 2480646Z20 COIL,CHIP,2.2UH,10%,MUL
TI-LAYER CHIP
L727M7 2480646Z20 COIL,CHIP,2.2UH,10%,MUL
TI-LAYER CHIP
L728M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
L733M7 2480646Z20 COIL,CHIP,2.2UH,10%,MUL
TI-LAYER CHIP
L735M7 2480646Z20 COIL,CHIP,2.2UH,10%,MUL
TI-LAYER CHIP
L738M7 2480646Z20 COIL,CHIP,2.2UH,10%,MUL
TI-LAYER CHIP
L739M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
L741M7 2480646Z20 COIL,CHIP,2.2UH,10%,MUL
TI-LAYER CHIP
L753M7 2415347H06 IDCTR,WW,2.2UH,5%,320M
A,1.2OHM,CER,SM,IDCTR,
2200NH
L755M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
L758M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
L759M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
L775M7 2415429H47 IDCTR,WW,390NH,5%,100
MA,CER,SM,CHIP
L901M16 2414017N10 IDCTR,CHIP,6.8NH,5%,600
MA,.22OHM,CER,12
Q,2.7GHZ SRF,SM,0603
L902M16 2415429H37 IDCTR,WW,110NH,5%,300
MA,.61OHM,CER,SM,0603,
CHIP
L903M16 2414015A07 IDCTR,FXD,180NH,2%,750
MA,.77OHM,CER,25
Q,700MHZ SRF,SM,1008
L904M16 2414017N18 IDCTR,CHIP,33NH,5%,600
MA,.71OHM,CER,12
Q,1.1GHZ SRF,SM,0603
Ref. Des. Part Number Description
L905M16 2414017N14 IDCTR,CHIP,15NH,5%,600
MA,.4OHM,CER,12
Q,1.8GHZ SRF,SM,0603,P
L906M16 2460591K40 IDCTR,FXD,15%,12
TURNS,COUNTERCLOCK-
WISE,28 AWG,SM,HI
L907M16 2471968L13 IDCTR,AW,5.5NH,2%,SM,L
OW PROFILE MINI SPR
IDCTR
L908M16 2415428H01 COIL,AW,1.65NH,10%,1.6A,
AIR,2 TURNS,SM,AIR
WOUND IDCTR
L909M16 2471968L10 IDCTR,AW,9NH,2%,4A,.003
4OHM,AIR,5 TURNS,120
Q,4GHZ SRF,SM,9.
L910M16 2471968L07 FIXED INDUC-
TOR,AW,18NH,2%,4A,AIR,
SM,LOW PROFILE MINI
SPR
M101M12 39012039001 CONN,CMPRSN,3CONT,ST
,CONNECTOR, BAT CON-
TACT, WWP
M103M12 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M104M12 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M105M12 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M1301M3 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M6405M6 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M6406M6 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
M6502M6 0985888K02 BATTERY CONNEC-
TOR,SKT,NI,LEAP
M6504M6 3987977Y04 CONT,CONN,1CONT,ANT
UNIV 4.5MM,UC 1.8
PCB PC000352A0
1
PCB
Q1101M11 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,
PB-FREE
Ref. Des. Part Number Description
Q1103M11 4813970A59 XSTR,FET GP PWR,P-
CH,ENHN,SM,SOT-
23,20V,.4W,PB-FREE
Q201M12 4813970A59 XSTR,FET GP PWR,P-
CH,ENHN,SM,SOT-
23,20V,.4W,PB-FREE
Q202M12 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,
PB-FREE
Q2202M2 4815261H01 XSTR,BIP GP
SS,NPN,DTC114Y,SC-
59,SC-
59,SMT3,50V,100MA,250M
HZ
Q2701M13 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
PNP,UMC5NT2G,SM,50V,1
00A
Q303M20 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q304M20 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,
PB-FREE
Q3227M22 4885061Y01 XSTR,BIP RF SMALL SIG-
NAL
Q3232M22 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
PNP,UMC5NT2G,SM,50V,1
00A
Q3267M22 4885061Y01 XSTR,BIP RF SMALL SIG-
NAL
Q3272M22 4815055H01 XSTR,GEN PURPOSE
SMALL SIG,NPN AND
PNP,UMC5NT2G,SM,50V,1
00A
Q4001M2 4815261H01 XSTR,BIP GP
SS,NPN,DTC114Y,SC-
59,SC-
59,SMT3,50V,100MA,250M
HZ
Ref. Des. Part Number Description
Q601M19 4813973A04 XSTR,BIP GP
SS,NPN,TA13,SM,SOT-
23,SMT,30V,.225W,300MA,1
25MHZ,P
Q6101M6 4815261H01 XSTR,BIP GP
SS,NPN,DTC114Y,SC-
59,SC-
59,SMT3,50V,100MA,250M
HZ
Q6401M6 48013068001 XSTR,FET GP PWR,N-
CH,SM,SOT-
563,SMT,20V,.25W,DL N-CH
20 V
Q6501M6 4813970A62 XSTR,FET GP PWR,MOS-
FET,P-CH,ENHN,CF,-
20V,1.3W,PB-FREE
Q6502M6 48012154001 XSTR,FET GP
PWR,P,SM,SMT,-
20V,.5W,FET
Q6504M6 4809579E77 XSTR,FET GP SS,MOS-
FET,N-
CH,SM,30V,1.2X1.2MM
PKG W18 COMP
Q6505M6 4813970A62 XSTR,FET GP PWR,MOS-
FET,P-CH,ENHN,CF,-
20V,1.3W,PB-FREE
Q6506M6 4809579E77 XSTR,FET GP SS,MOS-
FET,N-
CH,SM,30V,1.2X1.2MM
PKG W18 COMP
Q6507M6 48013068001 XSTR,FET GP PWR,N-
CH,SM,SOT-
563,SMT,20V,.25W,DL N-CH
20 V
Q6508M6 48012154001 XSTR,FET GP
PWR,P,SM,SMT,-
20V,.5W,FET
Q731M7 4885061Y01 XSTR,BIP RF SMALL SIG-
NAL
Q745M7 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q756M7 4805585Q32 XSTR,BIP RF SML
SGNL,NPN,NE662M04,SM,
SOT-343,3.3V,TRANSITO
Ref. Des. Part Number Description
