Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: VHF (84012320001 / PC000352A01) 8-99
R1305M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1309M3 NOTPLACED 64AM DUMMY PART NUM-
BER
R1310M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1311M3 NOTPLACED 64AM DUMMY PART NUM-
BER
R1313M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1315M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1317M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1318M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1325M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1326M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1329M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1330M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1331M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1332M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1337M3 NOTPLACED 64AM DUMMY PART NUM-
BER
R1338M3 2113944A61 CAP,FXD,.5PF,.25PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
R1339M3 NOTPLACED 64AM DUMMY PART NUM-
BER
R1340M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R201M12 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R202M12 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
Ref. Des. Part Number Description
R21000M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21001M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21002M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21003M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21004M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21005M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21006M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21007M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21008M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2104M2 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R2105M2 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R2106M2 NOTPLACED 64AM DUMMY PART NUM-
BER
R2107M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2109M2 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R2110M2 0613952Q33 RES,MF,22,5,.0625,SM,040
2,200,PB-FREE
R2111M2 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R2113M2 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
Ref. Des. Part Number Description
R2114M2 0613952Q33 RES,MF,22,5,.0625,SM,040
2,200,PB-FREE
R2115M2 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R2116M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2117M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2118M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2120M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2129M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2130M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2131M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2132M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2133M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2135M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2136M2 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2137M2 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2138M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R2139M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2142M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2144M2 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2145M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2146M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2147M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2148M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2149M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2151M2 NOTPLACED 64AM DUMMY PART NUM-
BER
R2153M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2154M2 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2192M2 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2197M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2198M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2199M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2200M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
