8-100 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: VHF (84012320001 / PC000352A01)
R2202M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2204M2 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2206M2 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2207M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2235M2 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R2244M2 0613952Q72 RES,MF,910OHM,5%,.0625
W,SM,0402,PB-FREE
R2245M2 0613952Q63 RES,MF,390OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2246M2 0613952Q60 RES,MF,300OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2254M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2255M2 0613952R32 RES,MF,200KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2701M13 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R2702M13 NOTPLACED 64AM DUMMY PART NUM-
BER
R2703M13 0613952H47 RES,MF,82OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R2704M13 0613952H47 RES,MF,82OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R2705M13 0613952H47 RES,MF,82OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R2706M13 0662057B47 RES,CF,0OHM,5%,.1W,SM,
0603
Ref. Des. Part Number Description
R2803M1 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2804M1 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R2805M1 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R2806M1 0613952Q59 RES,MF,270OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2807M1 0613952Q56 RES,MF,200OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2808M1 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R2810M1 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2811M1 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R2812M1 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2813M1 NOTPLACED 64AM DUMMY PART NUM-
BER
R2817M1 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R310M20 0613952R22 RES,MF,75KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R311M20 0613952R27 RES,MF,120KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R312M20 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R313M20 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R314M20 0613952Q75 RES,MF,1.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R315M20 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R3200M22 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R3201M22 0613952Q23 RES,MF,8.2OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3202M22 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R3203M22 0613952Q69 RES,MF,680OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3204M22 0613952Q69 RES,MF,680OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3205M22 0613952Q69 RES,MF,680OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3206M22 0613952Q23 RES,MF,8.2OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3207M22 0613952Q69 RES,MF,680OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3214M22 NOTPLACED 64AM DUMMY PART NUM-
BER
R3218M22 0613952Q93 RES,MF,6.8KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R3222M22 0613952Q96 RES,MF,9.1KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R3231M22 0613952Q58 RES,MF,240OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3233M22 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3257M22 0613952Q96 RES,MF,9.1KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R3260M22 0613952Q96 RES,MF,9.1KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R3271M22 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3273M22 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R380M20 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R381M20 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R4005M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4006M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4007M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4008M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4009M2 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R4010M2 0613952R32 RES,MF,200KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R4011M2 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R4012M2 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R4013M2 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R4014M2 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R500M21 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R502M21 0613952Q36 RES,MF,30OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
