Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1 (84012313002 / PC000353A01) 8-147

C1332M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1333M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1334M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1335M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1336M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C1337M3 2113944A28 CAP CER CHP 18.0PF 50V

C1338M3 2175389H01 CAP,.5PF, CHIP, 0402,

CERAMIC, 50 V

C1376M3 2113944A25 CAP CER CHP 10.0PF 50V

+/- 0.5PF

C1601M16 2113944M42 CAP,FXD,100PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1602M16 2113944M42 CAP,FXD,100PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1603M16 2113945L49 CAP,FXD,.01UF,+5%,-

5%,50V-DC,0603,X7R,-

55DEG CMIN,125DEG

CMAX,P

C1604M16 2113944M42 CAP,FXD,100PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1605M16 2113945B02 CAP CER CHP 10,000PF

25V 10%

C1606M16 2113944A40 CAP CER CHP 100.0PF

50V 5%

Ref. Des. Part Number Description

C1607M16 2113944M42 CAP,FXD,100PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1608M16 2113944M42 CAP,FXD,100PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1609M16 2113944A40 CAP CER CHP 100.0PF

50V 5%

C1610M16 2113944M14 CAP,FXD,6.8PF,.1PF+/-

,50V-DC,0603,C0G,-55DEG

CMIN,125DEG CMAX

C1611M16 2113945L49 CAP,FXD,.01UF,+5%,-

5%,50V-DC,0603,X7R,-

55DEG CMIN,125DEG

CMAX,P

C1612M16 NOTPLACED -

C1613M16 2113944M29 CAP,FXD,30PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1614M16 2113944M36 CAP,FXD,56PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1615M16 2113944A40 CAP CER CHP 100.0PF

50V 5%

C1616M16 2113944M34 CAP,FXD,47PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1617M16 2113945B02 CAP CER CHP 10,000PF

25V 10%

C1618M16 2113944M42 CAP,FXD,100PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1619M16 2113945C02 CAP CER CHP 10,000PF

50V 10%

C1620M16 2171741M09 CAP, CER CHIP, 68PF, 50V-

DC, HI Q CAP, 68 PF, 0805,

C0G, 5%

C1621M16 2171741M10 CAP, CER CHIP, 12PF,

100V-DC, HI Q CAP, 12 PF,

0805, C0G, 5%

Ref. Des. Part Number Description

C1622M16 2113944M20 CAP,FXD,12PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1623M16 NOTPLACED -

C1624M16 2113944M25 CAP,FXD,20PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1625M16 2113944M42 CAP,FXD,100PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1628M16 2113951C21 CAP,FXD,3PF,.05PF+/-

,250V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX

C1629M16 2113945A12 CAP CER CHP 3300PF 50V

10%

C1630M16 2113945A12 CAP CER CHP 3300PF 50V

10%

C1633M16 NOTPLACED -

C1803M17 2113944C17 CAP CER CHP 3.0PF 50V

+/- 0.25PF

C1804M17 2113951C05 CAP,FXD,.5PF,.05PF+/-

,250V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX

C1807M17 2113951C26 CAP,FXD,4.7PF,.05PF+/-

,250V-DC,0603,C0G,-

55DEG CMIN,125DEG CMA

C1820M17 2113944C16 CAP CER CHP 2.7PF 50V

+/- 0.25PF

C1821M17 2113944C26 CAP CER CHP 6.8PF 50V

+/- 0.5PF

C1822M17 2113944C45 CAP CER CHP 100.0PF

50V 5%

C1826M17 2113944C16 CAP CER CHP 2.7PF 50V

+/- 0.25PF

C1827M17 2113944C14 CAP CER CHP 2.2PF 50V

+/- 0.25PF

C1900M20 2115153H25 CAP, CERAMIC, COG

C1901M20 2115153H57 CAP, CERAMIC, COG

Ref. Des. Part Number Description

C1903M20 NOTPLACED -

C1920M20 2113946D07 CAP,CHIP,4.7UF,+10%,-

10%,6.3V-DC,0603,X5R,-

55DEG CMIN,85DEG CMA

C1922M20 2113944A40 CAP CER CHP 100.0PF

50V 5%

C1923M20 2113944A40 CAP CER CHP 100.0PF

50V 5%

C1924M20 2113946D07 CAP,CHIP,4.7UF,+10%,-

10%,6.3V-DC,0603,X5R,-

55DEG CMIN,85DEG CMA

C1925M20 2113944A40 CAP CER CHP 100.0PF

50V 5%

C1926M20 2113946B04 CAP CER CHP 0.10UF 10V

10%

C1928M20 2115153H21 CAP, CERAMIC, COG

C1929M20 2115153H27 CAP, CERAMIC, COG

C1930M20 NOTPLACED -

C1931M20 2115153H54 CAP, CERAMIC, COG

C1932M20 NOTPLACED -

C1935M20 2115153H13 CAP, CERAMIC, COG

C1936M20 2115153H26 CAP, CERAMIC, COG

C1938M20 2115153H15 CAP, CERAMIC, COG

C1939M20 2115153H13 CAP, CERAMIC, COG

C1940M20 2113944A40 CAP CER CHP 100.0PF

50V 5%

C1942M20 2115153H23 CAP, CERAMIC, COG

C1952M20 2115153H27 CAP, CERAMIC, COG

C1953M20 2115153H21 CAP, CERAMIC, COG

C1954M20 2113944A40 CAP CER CHP 100.0PF

50V 5%

C1955M20 2113946B04 CAP CER CHP 0.10UF 10V

10%

C1956M20 2115153H21 CAP, CERAMIC, COG

C1957M20 2115153H27 CAP, CERAMIC, COG

C1958M20 2115153H23 CAP, CERAMIC, COG

C1959M20 2115153H13 CAP, CERAMIC, COG

Ref. Des. Part Number Description

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)

Motorola APX 2000 Detailed Service Manual
