Motorola APX 2000 Detailed Service Manual

8-148 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1 (84012313002 / PC000353A01)
C1960M20 2115153H30 CAP, CERAMIC, COG
C1961M20 2115153H13 CAP, CERAMIC, COG
C1963M20 2115153H27 CAP, CERAMIC, COG
C1964M20 2115153H21 CAP, CERAMIC, COG
C1970M20 2115153H12 CAP, CERAMIC, COG
C1971M20 2115153H07 CAP, CERAMIC, COG
C200M12 2113945B02 CAP CER CHP 10,000PF
25V 10%
C201M12 2188468Y01 CAP CER 25V X7R 0805
1UF
C202M12 2188468Y01 CAP CER 25V X7R 0805
1UF
C203M12 2188468Y01 CAP CER 25V X7R 0805
1UF
C204M12 2113955D35 CAP,FXD,4.7UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C205M12 2113955D35 CAP,FXD,4.7UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C206M12 2113945B02 CAP CER CHP 10,000PF
25V 10%
C207M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C208M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C209M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C21000M2 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
C21001M2 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C21002M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C21003M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C21004M2 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C21005M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2104M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C210M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C2114M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2115M2 2113944A40 CAP CER CHP 100.0PF
50V 5%
C2116M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2126M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C2127M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C2128M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C2129M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C212M12 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C2130M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C213M12 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C214M12 2113944A40 CAP CER CHP 100.0PF
50V 5%
Ref. Des. Part Number Description
C215M12 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C216M12 2113944A40 CAP CER CHP 100.0PF
50V 5%
C217M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C2201M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2202M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2203M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2211M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2212M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2213M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2214M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2215M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2216M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2221M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2222M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2223M2 2113944A40 CAP CER CHP 100.0PF
50V 5%
C2401M2 NOTPLACED -
C2402M2 NOTPLACED -
C2403M2 NOTPLACED -
C2404M2 NOTPLACED -
C2601M13 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2602M13 2113944C45 CAP CER CHP 100.0PF
50V 5%
Ref. Des. Part Number Description
C2603M13 2113944A40 CAP CER CHP 100.0PF
50V 5%
C2604M13 2113944C45 CAP CER CHP 100.0PF
50V 5%
C2605M13 2113944A40 CAP CER CHP 100.0PF
50V 5%
C2606M13 2113944A40 CAP CER CHP 100.0PF
50V 5%
C2607M13 2113944C20 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C2608M13 2113944C20 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C2609M13 2113946K02 CAP CER CHP 0.10UF 16V
C2806M1 NOTPLACED -
C3100M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C3101M22 2115153H21 CAP, CERAMIC, COG
C3102M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C3103M22 NOTPLACED -
C3104M22 NOTPLACED -
C3105M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C3106M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C3107M22 2115153H23 CAP, CERAMIC, COG
C3108M22 NOTPLACED -
C3109M22 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3110M22 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C3111M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C3112M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C3113M22 2113944M15 CAP,FXD,7.5PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
Ref. Des. Part Number Description
