Motorola APX 2000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1 (84012313002 / PC000353A01) 8-149
C3115M22 2113944M14 CAP,FXD,6.8PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3116M22 2113944M14 CAP,FXD,6.8PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3120M22 2113944M42 CAP,FXD,100PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C3122M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C3133M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C3140M22 2115153H19 CAP, CERAMIC, COG
C3141M22 2115153H19 CAP, CERAMIC, COG
C3142M22 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3143M22 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C3144M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C3147M22 2113944M09 CAP,FXD,4.3PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3151M22 2113944M16 CAP,FXD,8.2PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3152M22 2113944M12 CAP,FXD,5.6PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C3154M22 2113944M35 CAP,FXD,51PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C3155M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C3157M22 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3158M22 2113946B04 CAP CER CHP 0.10UF 10V
10%
C3159M22 2113944A09 CAP CER CHP 2.2PF 50V
+/- 0.25PF
Ref. Des. Part Number Description
C3160M22 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C3161M22 2113944A40 CAP CER CHP 100.0PF
50V 5%
C4005M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C4006M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C4007M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C500M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C501M21 2113944A32 CAP CER CHP 39.0PF 50V
5%
C502M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C504M21 2113944A40 CAP CER CHP 100.0PF
50V 5%
C505M21 NOTPLACED -
C506M21 2113944A32 CAP CER CHP 39.0PF 50V
5%
C507M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C508M21 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C509M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C510M21 2113944A32 CAP CER CHP 39.0PF 50V
5%
C511M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C512M21 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C514M21 NOTPLACED -
C515M21 2113944A14 CAP CER CHP 3.6PF 50V
+/- 0.25PF
Ref. Des. Part Number Description
C516M21 2113944M42 CAP,FXD,100PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,P
C532M21 2113944A32 CAP CER CHP 39.0PF 50V
5%
C533M21 2115153H52 CAP, CERAMIC, COG
C550M21 NOTPLACED -
C551M21 NOTPLACED -
C601M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C602M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C603M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C604M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C605M19 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C606M19 2113946B04 CAP CER CHP 0.10UF 10V
10%
C607M19 2113944A40 CAP CER CHP 100.0PF
50V 5%
C608M19 2113944A12 CAP CER CHP 3.0PF 50V
+/- 0.25PF
C609M19 2113944A30 CAP CER CHP 27.0PF 50V
5%
C6104M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6105M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6106M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6107M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6108M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6109M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C610M19 2113944A40 CAP CER CHP 100.0PF
50V 5%
Ref. Des. Part Number Description
C6110M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6111M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6112M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6113M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6114M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6115M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C611M19 2113944A40 CAP CER CHP 100.0PF
50V 5%
C612M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C613M19 2113944A40 CAP CER CHP 100.0PF
50V 5%
C614M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C6155M6 NOTPLACED -
C6156M6 NOTPLACED -
C615M19 2113944A42 CAP CER CHP 150.0PF
50V 5%
C616M19 2113945A11 CAP CER CHP 2200PF 50V
10%
C617M19 2113946B04 CAP CER CHP 0.10UF 10V
10%
C618M19 2113944A31 CAP CER CHP 33.0PF 50V
5%
C619M19 2113944A35 CAP CER CHP 62.0PF 50V
5%
C6201M6 2113944A40 CAP CER CHP 100.0PF
50V 5%
C6202M6 2113945A09 CAP CER CHP 1000PF 50V
10%
C6203M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C620M19 2113946B04 CAP CER CHP 0.10UF 10V
10%
Ref. Des. Part Number Description
