Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1 (84012313002 / PC000353A01) 8-181
R6520M6 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6521M6 0615049H01 RES,MF,.2OHM,1%,.5W,120
6,KAMAYA 0.2 OHM CHIP
RES
R6522M6 0613952M66 CER CHIP RES 4750 OHM
1% 0402
R6523M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R6524M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6525M6 NOTPLACED 64AM DUMMY PART NUM-
BER
R6526M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6527M6 0613952N87 RES,MF,78.7KOHM,1%,.06
25W,SM,0402,200PPM/
CEL,PB-FREE
R6528M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6529M6 0615049H01 RES,MF,.2OHM,1%,.5W,120
6,KAMAYA 0.2 OHM CHIP
RES
R6530M6 0613952L30 RES,MF,200OHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6531M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6532M6 NOTPLACED 64AM DUMMY PART NUM-
BER
R6533M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6534M6 NOTPLACED 64AM DUMMY PART NUM-
BER
R6535M6 0613952N01 RES:MF,10KOHM,1%,.0625
W,SM,0402*
R6536M6 0613952Z72 RES,MF,91KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R6537M6 0613952P09 CER CHIP RES 121K OHM
1 0402
R6538M6 0613952Q95 RES,MF,8.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6539M6 0613952P66 RES,MF,475KOHM,1%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6540M6 0613952P66 RES,MF,475KOHM,1%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6541M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6542M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6543M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6544M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6545M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6546M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6547M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6548M6 NOTPLACED 64AM DUMMY PART NUM-
BER
R6550M6 0613952Z64 RES,MF,39KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6551M6 0613952Z62 RES,MF,33KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6552M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6558M6 0613952P22 RES,MF,165KOHM,1%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6561M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
R6562M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6563M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6564M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6565M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6566M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6567M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6568M6 0613952P47 RES,MF,301KOHM,1%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6570M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6574M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6576M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6577M6 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R6578M6 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R6579M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6580M6 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R6581M6 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R6582M6 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R6583M6 0613952R03 RES,MF,12000,5,.0625,SM,
0402,200,PB-FREE
R6584M6 0613952Q56 RES,MF,200OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6592M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
R6598M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6599M6 NOTPLACED 64AM DUMMY PART NUM-
BER
R6601M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6602M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6604M6 0613952Q51 RES,MF,120,5,.0625,SM,04
02,200,PB-FREE
R6605M6 0613952Q33 RES,MF,22,5,.0625,SM,040
2,200,PB-FREE
R6606M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6608M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6609M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6616M6 0613952Q80 RES,MF,2KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6617M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6618M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6619M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6621M6 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R6622M6 0613952Q35 RES,MF,27OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6623M6 0613952Q35 RES,MF,27OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
