8-182 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1 (84012313002 / PC000353A01)
R6624M6 0613952Q35 RES,MF,27OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6625M6 0613952Q35 RES,MF,27OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6626M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R698M19 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R699M19 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R701M7 0613952Q64 RES,MF,430OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R702M7 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R703M7 0613952Q67 RES,MF,560OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R704M7 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R705M7 0613952Q71 RES,MF,820OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R706M7 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R707M7 0613952Q67 RES,MF,560OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R708M7 0613952Q45 RES,MF,68OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R709M7 NOTPLACED 64AM DUMMY PART NUM-
BER
R721M7 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R722M7 0613952Q71 RES,MF,820OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R723M7 0613952Q79 RES,MF,1800,5,.0625,SM,0
402,200,PB-FREE
Ref. Des. Part Number Description
R728M7 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R729M7 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R730M7 0613952Q84 RES,MF,3KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R736M7 0613952Q55 RES,MF,180OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R741M7 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R742M7 0613952R23 RES,MF,82KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R743M7 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R744M7 0613952Q91 RES,MF,5600,5,.0625,SM,0
402,200,PB-FREE
R745M7 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R746M7 0613952Q34 RES,MF,24OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R747M7 0613952Q39 RES,MF,39OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R748M7 0613952Q47 RES,MF,82OHM,5%,.0625
W,SMD,0402,200PPM/
CEL,CER CHIP 82.0 OHM
5%
R751M7 0613952Q59 RES,MF,270OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R754M7 NOTPLACED 64AM DUMMY PART NUM-
BER
R757M7 0613952Q59 RES,MF,270OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R761M7 0613952Q23 RES,MF,8.2OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R762M7 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R763M7 0613952R19 RES,MF,56KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R766M7 0613952Q92 RES,MF,6.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R769M7 0613952Q31 RES,MF,18OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R771M7 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R776M7 0613952Q67 RES,MF,560OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R778M7 0613952Q32 RES,MF,20OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R779M7 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R785M7 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R799M7 0613952Q53 RES,MF,150OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R809M7 0613952Q38 RES,MF,36OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R822M7 NOTPLACED 64AM DUMMY PART NUM-
BER
R823M7 NOTPLACED 64AM DUMMY PART NUM-
BER
T506M21 2575851B01 XFMR,BALUN,RF XFMR
BALUN
T507M21 2575851B02 XFMR,BALUN,25,SM,RF
XFMR BALUN
U1101M11 5188032U43 IC,SENSING CIR-
CUIT,INA138,SM,SOT-23/
5,1PER PKG
U1103M11 5185070Y01 IC,TEMP SENS
Ref. Des. Part Number Description
U1104M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1105M11 5180390L83 IC,CNTLR,SM,1PER PKG
U1106M11 5175772B05 IC,LTC5532ES6,SOT-
23,1PER PKG,PRCN RF
DET
U1112M11 5175772B04 IC,HMC468LP3E,QFN,1 DB
LSB GAAS MMIC ATTEN
U1113M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1114M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1119M11 5109522E94 GATE,AND,1PER
PKG,SM,2 INPUT IN NANO
PKG
U1121M11 5114000B52 IC,XOR,LOGIC LEVEL
SHIFTER,1PER
PKG,SM,SOT-353,PB-FREE
U1125M11 5175206H01 IC,DAC,W/ 5 PPM/C INT
REF
U1126M11 5109817F77 IC,COMPTR,LMV7275,SC7
0-5
U1127M11 5171779H01 IC,ANLG SW,SC70,SC70-
6,1PER PKG,SPDT ANLG
SW
U1128M11 5188085K11 IC,NAND,SINGLE 2
INPUT,SN74LVC1G00YZPR
,SM,GATE, POS, 5 DSBGA,
U1129M11 5175143H01 IC,WIDE SPLY RANGE OP
AMP
U1130M11 5175143H01 IC,WIDE SPLY RANGE OP
AMP
U1131M11 5109817F77 IC,COMPTR,LMV7275,SC7
0-5
U1132M11 5114007M28 IC,D FLIP-FLOP,1PER
PKG,17SZ74,N-
I,SM,SOIC8,PB-FREE
U1133M11 5171779H01 IC,ANLG SW,SC70,SC70-
6,1PER PKG,SPDT ANLG
SW
Ref. Des. Part Number Description
