Motorola APX 2000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF1 (84012313002 / PC000353A01) 8-183
U1136M11 5109522E94 GATE,AND,1PER
PKG,SM,2 INPUT IN NANO
PKG
U1137M11 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U1138M11 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U1139M11 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U1141M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1142M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1143M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1144M11 5171779H01 IC,ANLG SW,SC70,SC70-
6,1PER PKG,SPDT ANLG
SW
U1146M11 5109522E93 GATE,OR,SN74LVC1G32Y
ZPR,1PER PKG,SM,2
INPUT IN NANO PKG
U1147M11 5109522E94 GATE,AND,1PER
PKG,SM,2 INPUT IN NANO
PKG
U1148M11 5185941F56 IC,OP AMP,1PER
PKG,RAIL-RAIL,SOIC,IC
SNGL LV LP OP AMP
U1149M11 5109522E93 GATE,OR,SN74LVC1G32Y
ZPR,1PER PKG,SM,2
INPUT IN NANO PKG
U1150M11 51009381001 IC,MICROPOWER SOT-23
V REF
U1301M3 51007377001 IC,XCVR,NL5500,BGA,BLU-
ETOOTH, GPS, FM RX, FM
TX
Ref. Des. Part Number Description
U1304M3 51007599001 AMP,20.0DB,1.58GHZMIN,1
.58GHZMAX,SLCN GER-
MANIUM GPS LOW NOISE
AM
U1305M3 5187344N09 IC,LNR V
REGLTR,FXD,2.8V,100MA,L
OW NOISE
U1601M16 5175143H01 IC,WIDE SPLY RANGE OP
AMP
U1602M16 51012101001 VHF/UHF/800/900 MHZ
LDMOS DRIVER IC
U1932M20 4885316E32 XSTR,BIP RF SML
SGNL,SLCN,BFR380F,SM,
SMT,6V,380W,80A,14MHZ,T
R
U200M12 5188493T01 IC,VREG/
SWG,LP2989,SM,MINI SO-
8 HI PRCN REG 5V
U201M12 5175771A99 IC,LNR V
REGLTR,FXD,100MA,VFBG
A,LOW NOISE, 100MA LIN-
EAR REGL
U202M12 5175772B02 IC,LNR V
REGLTR,FXD,1.8V,100MA,
VFBGA,LINEAR REGLTR
100MA 1.8
U203M12 5175772B01 IC,LNR V
REGLTR,FXD,1.5V,350MA,
VFBGA,LINEAR V REGLTR
350MA
U2101M2 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U2102M2 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U2201M2 5171679H01 IC,DISP DRVR,LED LT
DRVR
U2202M2 5164852H47 IC,XLTR,2PER
PKG,TSSOP8,IC, I2C LEV
XLTR
U2601M13 5103535B53 IC,INVTR,DL,NC7WZ04L6X
,2PER PKG,SC70
U2602M13 5185941F45 ATTEN,VAR,14.4DBMIN,15.
6DBMAX,0-2000 MHZ-
FREQ,50OHM,PCMT,SOT-
25
Ref. Des. Part Number Description
U3001M22 5171972L01 IC,SW,SP3T RF SW
U4001M2 5164852H47 IC,XLTR,2PER
PKG,TSSOP8,IC, I2C LEV
XLTR
U4003M2 5188691V01 IC,MUX/
DEMUX,NC7SB3157P6X,S
M,SC70-6,1PER
PKG,BUS,PB FREE
U4004M2 5116783H01 IC,ANLG
SW,SN74LVC2G66YZPR,S
M,2PER
PKG,0CHANNELS,BILAT-
ERAL,DL
U507M21 5164015H81 IC,MXR,SM
U601M19 5102495J14 IC,IF,IF DIGITILIZING SUB-
SYSTEM IC,AD9864,QFN
U602M19 4885316E32 XSTR,BIP RF SML
SGNL,SLCN,BFR380F,SM,
SMT,6V,380W,80A,14MHZ,T
R
U603M19 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U604M19 5109522E84 IC,DL SCHT TRIG MICRO
PAK
U605M19 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U606M19 5164852H16 IC,TRANSLATING,2PER
PKG,LVC2T45,TRANS-
CEIVER W/VOLTAGE
TRANSLATI
U607M19 5186311J24 IC,BFR,1PER
PKG,NC7SZ125,ACTIVE
HIGH,BFR,3ST,SM,5.5
U6101M6 0180706J18 IC,PGM,PGM CPLD
U6102M6 5188691V01 IC,MUX/
DEMUX,NC7SB3157P6X,S
M,SC70-6,1PER
PKG,BUS,PB FREE
U6103M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6104M6 5175114H01 IC,SNGL AND GATE
MICROPAK
Ref. Des. Part Number Description
U6105M6 5175114H01 IC,SNGL AND GATE
MICROPAK
U6201M6 5185941F26 IC,COMPTR,LMV7219,SM,
SOT-23/5,IC,LM7219,COM-
PARATOR,NOPB
U6301M6 51012058002 IC,SDRAM,512MBITS,8
MEG X 16 X 4
BANKS,6NS,SM,MOBILE
LPDDR 5
U6302M6 5102495J13 IC,MICROP,P1710ZZGE,BG
A,12MHZ,32BITS
U6304M6 0105955U25 ASSY,ASSY,ASSY,IC,BGA
SPEC PROG, FLSH MEM
U6401M6 5175772B38 IC,IC ANLG TEMP SENSOR
U6402M6 5115453H01 IC,OP AMP,2PER PKG,RAIL
TO RAIL OUTPUT, 8 PIN
BGA
U6404M6 5175772B38 IC,IC ANLG TEMP SENSOR
U6405M6 5188348V06 IC,AUDIO
CODEC,SM,AUDIO CODEC
U6408M6 5188521T01 IC,VREF,SM,SOT23,1PER
PKG,.5%,1.25 TO
13.75,PRCN BANDGAP
ADJUS
U6409M6 51009000001 IC,COMPTR,SC70,NANOP-
OWER, 1.8V, SC70
COMPTR
U6410M6 5175772B38 IC,IC ANLG TEMP SENSOR
U6411M6 5109731C55 IC,AU AMP,BGA,2.75 FXD
GAIN MONO FLTR-FREE
U6501M6 5185143E77 IC,CUST,BGA,IC, MAKO
ASIC, CMOS PWR MGMT
U6502M6 4871987H01 XSTR,BIP GP
POWER,12V,1A,LOW
FREQ XSTR
U6503M6 5171674H01 IC,OP AMP,SO-8,OP AMP
U6504M6 5171682H01 IC,DC TO DC CON-
VERTER,800MA BUCK
REGLTR
U6505M6 5189631P01 IC,0PER PKG,SYNC STEP-
DOWN CONV
U6506M6 5184790Y04 IC,LINEAR VOLTAGE REG-
ULATOR,400MA
Ref. Des. Part Number Description

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
