8-254 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2 (84012432001 / PC000354A01)
Q731M7 4885061Y01 XSTR,BIP RF SMALL SIG-
NAL
Q745M7 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q756M7 4805585Q32 XSTR,BIP RF SML
SGNL,NPN,NE662M04,SM,
SOT-343,3.3V,TRANSITO
Q767M7 4813973M75 XSTR,BIP GP
SS,PNP,BC858,SOT-
563,SMT,-30V,.357W,-
100MA,100MHZ
Q774M7 4805585Q32 XSTR,BIP RF SML
SGNL,NPN,NE662M04,SM,
SOT-343,3.3V,TRANSITO
Q785M7 4889394V04 XSTR,FET GEN PURPOSE
SMALL SIG,MOSFET,N-
CH,ENHN,SM,20V,.25W,P
R1101M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1102M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1103M11 06012035001 RES,MF,.02OHM,1%,.33W,
SM,0805, 0.02 OHM, CHIP
RES
R1104M11 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R1105M11 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R1106M11 0613952Q21 RES,MF,6.8OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1107M11 0613952Q45 RES,MF,68OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1108M11 0613952N81 RES,MF,68.1KOHM,1%,.06
25W,SM,0402,200PPM/
CEL,PB-FREE
R1110M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R1111M11 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1112M11 NOTPLACED 64AM DUMMY PART NUM-
BER
R1114M11 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R1115M11 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R1116M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1117M11 0613952R11 RES,MF,27KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1121M11 0613952N47 RES,MF,30.1KOHM,1%,.06
25W,SM,0402,200PPM/
CEL,PB-FREE
R1122M11 0613952N85 RES,MF,75KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1124M11 0613952Q42 RES,MF,51OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1125M11 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R1126M11 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R1127M11 0613952R08 RES,MF,20KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1128M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1129M11 NOTPLACED 64AM DUMMY PART NUM-
BER
R1130M11 NOTPLACED 64AM DUMMY PART NUM-
BER
R1135M11 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1136M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R1137M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1138M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1139M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1140M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1141M11 0613952R42 RES,MF,510KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1142M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1143M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1144M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1145M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1146M11 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1151M11 0613952R05 RES,MF,15KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1152M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1154M11 0613952N01 RES,MF,10KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1158M11 NOTPLACED 64AM DUMMY PART NUM-
BER
R1160M11 0613952R03 RES,MF,12000,5,.0625,SM,
0402,200,PB-FREE
Ref. Des. Part Number Description
R1162M11 0613952R29 RES,MF,150KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1163M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1164M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1165M11 0613952Q56 RES,MF,200OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1166M11 0613952Q56 RES,MF,200OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1167M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1168M11 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R1169M11 0613952P52 RES,MF,340KOHM,1%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1170M11 0613952N88 RES,MF,80.6KOHM,1%,.06
25W,SM,0402,200PPM/
CEL,PB-FREE
R1171M11 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1172M11 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R1174M11 0613952N01 RES,MF,10KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1175M11 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1176M11 0613952M01 RES,MF,1KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1177M11 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1178M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
