Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2 (84012432001 / PC000354A01) 8-255
R1180M11 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1181M11 NOTPLACED 64AM DUMMY PART NUM-
BER
R1182M11 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1198M11 0613952J01 RES,MF,10KOHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R1301M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1303M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1305M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1309M3 NOTPLACED 64AM DUMMY PART NUM-
BER
R1310M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1311M3 NOTPLACED 64AM DUMMY PART NUM-
BER
R1313M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1315M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1317M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1318M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1325M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1326M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1329M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1330M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1331M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1332M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
R1337M3 NOTPLACED 64AM DUMMY PART NUM-
BER
R1339M3 NOTPLACED 64AM DUMMY PART NUM-
BER
R1340M3 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1601M16 0613952Q96 RES,MF,9.1KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1602M16 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1603M16 0613952R22 RES,MF,75KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1604M16 0613952R13 RES,MF,33KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1605M16 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1606M16 0613952H53 RES,MF,150OHM,5%,.1W,S
M,0603,200PPM/CEL,PB-
FREE
R1651M16 NOTPLACED 64AM DUMMY PART NUM-
BER
R1652M16 NOTPLACED 64AM DUMMY PART NUM-
BER
R1653M16 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1900M20 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1906M20 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1907M20 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1908M20 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1909M20 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R1910M20 0613952Q96 RES,MF,9.1KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1911M20 0613952Q96 RES,MF,9.1KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1921M20 0613952R22 RES,MF,75KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1922M20 0613952R27 RES,MF,120KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1923M20 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1924M20 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1925M20 0613952Q11 RES,MF,2.7OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R1935M20 0613952Q75 RES,MF,1.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R1936M20 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R1970M20 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R1972M20 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R201M12 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R202M12 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R21000M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21001M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21002M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R21003M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21004M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21005M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21006M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21007M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R21008M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2104M2 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R2105M2 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R2106M2 NOTPLACED 64AM DUMMY PART NUM-
BER
R2107M2 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R2109M2 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R2110M2 0613952Q33 RES,MF,22,5,.0625,SM,040
2,200,PB-FREE
R2111M2 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R2113M2 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R2114M2 0613952Q33 RES,MF,22,5,.0625,SM,040
2,200,PB-FREE
R2115M2 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R2116M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
