Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2 (84012432001 / PC000354A01) 8-257
R3127M22 0613952Q52 RES,MF,130OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3146M22 0613952R11 RES,MF,27KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3149M22 0613952R07 RES,MF,18KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3158M22 0613952Q46 RES,MF,75OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3159M22 0613952Q40 RES,MF,43OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R3160M22 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R4005M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4006M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4007M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4008M2 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R4009M2 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R4010M2 0613952R32 RES,MF,200KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R4011M2 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R4012M2 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R4013M2 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R4014M2 0613952Q85 RES,MF,3.3KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R500M21 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R502M21 0613952Q36 RES,MF,30OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R512M21 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R525M21 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R526M21 0613958J74 RES,MF,0OHM,5%,.125W,S
M,0805,PB-FREE
R601M19 0613952Q41 RES,MF,47OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R602M19 0613952Q63 RES,MF,390OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R603M19 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R604M19 0613952Q63 RES,MF,390OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R605M19 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R606M19 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R607M19 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R608M19 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R609M19 0613952Q81 RES,MF,2200,5,.0625,SM,0
402,200,PB-FREE
R6101M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6102M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
Ref. Des. Part Number Description
R6103M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R6104M6 NOTPLACED 64AM DUMMY PART NUM-
BER
R6105M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6106M6 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6107M6 0613952Q55 RES,MF,180OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6108M6 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6109M6 NOTPLACED 64AM DUMMY PART NUM-
BER
R610M19 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6110M6 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6111M6 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6112M6 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6113M6 0613952Q51 RES,MF,120,5,.0625,SM,04
02,200,PB-FREE
R6114M6 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R6115M6 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
R6116M6 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6117M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6118M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
Ref. Des. Part Number Description
R6119M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R611M19 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6120M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6121M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6122M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6125M6 NOTPLACED 64AM DUMMY PART NUM-
BER
R612M19 0613952Q94 RES,MF,7.5KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R613M19 0613952Q82 RES,MF,2.4KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R614M19 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R615M19 NOTPLACED 64AM DUMMY PART NUM-
BER
R616M19 NOTPLACED 64AM DUMMY PART NUM-
BER
R617M19 NOTPLACED 64AM DUMMY PART NUM-
BER
R618M19 NOTPLACED 64AM DUMMY PART NUM-
BER
R619M19 NOTPLACED 64AM DUMMY PART NUM-
BER
R6201M6 NOTPLACED 64AM DUMMY PART NUM-
BER
R6202M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6203M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
