8-258 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: UHF2 (84012432001 / PC000354A01)
R6204M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6205M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6206M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6207M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6208M6 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R6209M6 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R620M19 NOTPLACED 64AM DUMMY PART NUM-
BER
R6210M6 0613952Q89 RES,MF,4700,5,.0625,SM,0
402,200,PB-FREE
R6211M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6212M6 NOTPLACED 64AM DUMMY PART NUM-
BER
R6213M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6214M6 NOTPLACED 64AM DUMMY PART NUM-
BER
R6215M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6217M6 0613952Q73 RES,MF,1KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6218M6 0613952Q80 RES,MF,2KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R621M19 NOTPLACED 64AM DUMMY PART NUM-
BER
R623M19 NOTPLACED 64AM DUMMY PART NUM-
BER
Ref. Des. Part Number Description
R624M19 NOTPLACED 64AM DUMMY PART NUM-
BER
R6301M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6304M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6306M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6310M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6311M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6312M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6313M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6314M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6316M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6401M6 0613952R18 RES,MF,51KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6402M6 0613952R32 RES,MF,200KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6403M6 0613952Q81 RES,MF,2200,5,.0625,SM,0
402,200,PB-FREE
R6404M6 0613952Q81 RES,MF,2200,5,.0625,SM,0
402,200,PB-FREE
R6405M6 0613952Q75 RES,MF,1.2KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6406M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R6407M6 0613952Q81 RES,MF,2200,5,.0625,SM,0
402,200,PB-FREE
R6409M6 0613952N01 RES,MF,10KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6410M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6411M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6414M6 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6415M6 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6416M6 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6417M6 0613952Q61 RES,MF,330OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6419M6 0613952Q37 RES,MF,33OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6420M6 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R6421M6 0613952R01 RES,MF,10KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6422M6 0613952Q51 RES,MF,120,5,.0625,SM,04
02,200,PB-FREE
R6423M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
R6424M6 0613952N01 RES,MF,10KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6425M6 0613952Q80 RES,MF,2KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6426M6 0613952Q49 RES,MF,100,5,.0625,SM,04
02,200,PB-FREE
Ref. Des. Part Number Description
R6427M6 0613952R11 RES,MF,27KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6428M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6429M6 0613952R17 RES,MF,47000,5,.0625,SM,
0402,200,PB-FREE
R6430M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R6431M6 0613952Q81 RES,MF,2200,5,.0625,SM,0
402,200,PB-FREE
R6432M6 0613952R25 RES,MF,100KOHM,5%,.062
5W,SM,0402,200PPM/
CEL,PB-FREE
R6433M6 0613952Q32 RES,MF,20OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6434M6 0613952Q32 RES,MF,20OHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6435M6 0613952N01 RES,MF,10KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6436M6 NOTPLACED 64AM DUMMY PART NUM-
BER
R6492M6 0613952Q79 RES,MF,1800,5,.0625,SM,0
402,200,PB-FREE
R6501M6 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R6502M6 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R6503M6 0613952Q25 RES,MF,10,5,.0625,SM,040
2,200,PB-FREE
R6504M6 0613952R09 RES,MF,22000,5,.0625,SM,
0402,200,PB-FREE
R6505M6 0613952Q80 RES,MF,2KOHM,5%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6506M6 0613952R66 RES,MF,0OHM,5%,.0625W,
SM,0402,PB-FREE
Ref. Des. Part Number Description
