Motorola APX 2000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01) 8-301
700/800 MHz Transceiver (RF) Board Parts List
– 84012266001
Ref. Des. Part Number Description
C1001M16 2113944M30 CAP,FXD,33PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1002M16 2113944C22 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C1003M16 2113945C02 CAP CER CHP 10,000PF
50V 10%
C1004M16 2113944M30 CAP,FXD,33PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1005M16 2113944M30 CAP,FXD,33PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1006M16 2113945C02 CAP CER CHP 10,000PF
50V 10%
C1007M16 2113944M30 CAP,FXD,33PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1008M16 2113944M30 CAP,FXD,33PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1009M16 2113944M30 CAP,FXD,33PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1010M16 2113945C02 CAP CER CHP 10,000PF
50V 10%
C1013M16 2113944M21 CAP,FXD,13PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1014M16 NOTPLACED –
C1015M16 2113944M30 CAP,FXD,33PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1018M16 2113944M30 CAP,FXD,33PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1019M16 2171741M03 HIGH Q CAP
C101M12 2113944A31 CAP CER CHP 33.0PF 50V
5%
C1020M16 2113944M11 CAP,FXD,5.1PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1021M16 2113944M01 CAP,FXD,2PF,.1PF+/-,50V-
DC,0603,C0G,-55DEG
CMIN,125DEG CMAX,PB
C1022M16 2113944M30 CAP,FXD,33PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1023M16 2113944M24 CAP,FXD,18PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1024M16 2113945A12 CAP CER CHP 3300PF 50V
10%
C1025M16 2113945A12 CAP CER CHP 3300PF 50V
10%
C1026M16 2113945C07 CAP CER CHP 330PF 50V
10%
C1101M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1102M11 2188468Y01 CAP CER 25V X7R 0805
1UF
C1103M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1104M11 NOTPLACED –
C1105M11 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C1106M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1107M11 2113944A40 CAP CER CHP 100.0PF
50V 5%
C1108M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
Ref. Des. Part Number Description
C1110M11 2113944A31 CAP CER CHP 33.0PF 50V
5%
C1111M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1112M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1113M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1116M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1117M11 2113945A12 CAP CER CHP 3300PF 50V
10%
C1118M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1119M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1120M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1122M11 2113944M02 CAP,FXD,2.2PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1123M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1124M11 2113945A13 CAP CER CHP 4700PF 50V
10%
C1125M11 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C1126M11 2113945A09 CAP CER CHP 1000PF 50V
10%
C1127M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1128M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1129M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1130M11 2113945B02 CAP CER CHP 10,000PF
25V 10%
Ref. Des. Part Number Description
C1135M11 NOTPLACED –
C1137M11 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C1138M11 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C1139M11 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5PF
C1140M11 2113945A13 CAP CER CHP 4700PF 50V
10%
C1141M11 2175793A01 CAP CHIP .47 UF 0402
6.3V X5R
C1142M11 2113945A09 CAP CER CHP 1000PF 50V
10%
C1155M11 NOTPLACED –
C1160M11 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C1161M11 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C1165M11 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1301M3 2172180Y01 CAP,CHIP,2.2UF,+20%,-
20%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
C1302M3 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C1303M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
C1304M3 2113944A26 CAP CER CHP 12.0PF 50V
5%
C1305M3 2113945B02 CAP CER CHP 10,000PF
25V 10%
C1306M3 2187893N01 CAP 1UF, 6.3V, X5R, 0402
PACKAGE
Ref. Des. Part Number Description

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
