Motorola APX 2000 Detailed Service Manual

8-302 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01)
C1307M3 2113944A26 CAP CER CHP 12.0PF 50V
5%
C1308M3 2113945A09 CAP CER CHP 1000PF 50V
10%
C1309M3 2113944A26 CAP CER CHP 12.0PF 50V
5%
C1310M3 2187893N01 CAP 1UF, 6.3V, X5R, 0402
PACKAGE
C1311M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
C1312M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
C1313M3 2187893N01 CAP 1UF, 6.3V, X5R, 0402
PACKAGE
C1314M3 2113944M20 CAP,FXD,12PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C1315M3 2175389H01 CAP,.5PF, CHIP, 0402,
CERAMIC, 50 V
C1317M3 2188881Y12 CAPACITOR CERAMIC
NPO HIGH FREQUENCY
16 VOLT (REPLACES
2104801Z12)
C1318M3 2113944A13 CAP CER CHP 3.3PF 50V
+/- 0.25PF
C1319M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1320M3 2113944A28 CAP CER CHP 18.0PF 50V
5%
C1321M3 2113944A29 CAP CER CHP 22.0PF 50V
5%
C1322M3 2113944A29 CAP CER CHP 22.0PF 50V
5%
C1323M3 2113944A29 CAP CER CHP 22.0PF 50V
5%
C1324M3 2115153H03 CAP, CERAMIC, COG
Ref. Des. Part Number Description
C1325M3 2113944A29 CAP CER CHP 22.0PF 50V
5%
C1326M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1327M3 2113944A28 CAP CER CHP 18.0PF 50V
5%
C1328M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1329M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1330M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1331M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1332M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1333M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1334M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1335M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1336M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C1337M3 2113944A28 CAP CER CHP 18.0PF 50V
5%
Ref. Des. Part Number Description
C1338M3 2175389H01 CAP,.5PF, CHIP, 0402,
CERAMIC, 50 V
C1376M3 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5PF
C1411M17 2113944C36 CAP CER CHP 33.0PF 50V
5%
C1413M17 2113944C10 CAP CER CHP 1.5PF 50V
+/- 0.25PF
C1414M17 NOTPLACED –
C1418M17 2113944C08 CAP CER CHP 1.2PF 50V
+/- 0.25PF
C1419M17 2113944C67 CAP,FXD,1.5PF,.1PF+/-
,50V-DC,0603,C0G,-55DEG
CMIN,125DEG CMAX
C1424M17 2113742C09 CAP CER CHP 0.9PF +-
.10PF 100V
C1425M17 2113944C12 CAP CER CHP 1.8PF 50V
+/- 0.25PF
C200M12 2113945B02 CAP CER CHP 10,000PF
25V 10%
C201M12 2188468Y01 CAP CER 25V X7R 0805
1UF
C202M12 2188468Y01 CAP CER 25V X7R 0805
1UF
C203M12 2188468Y01 CAP CER 25V X7R 0805
1UF
C204M12 2113955D35 CAP,FXD,4.7UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C205M12 2113955D35 CAP,FXD,4.7UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C206M12 2113945B02 CAP CER CHP 10,000PF
25V 10%
C207M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
Ref. Des. Part Number Description
C208M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C209M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C21000M2 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C21001M2 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C21002M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C21003M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C21004M2 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C21005M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2104M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C210M12 2113956B91 CAP,FXD,1UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX,PB
C2114M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2115M2 2113944A40 CAP CER CHP 100.0PF
50V 5%
C2116M2 2113946B04 CAP CER CHP 0.10UF 10V
10%
C2126M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C2127M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C2128M2 2113944A46 CAP CER CHP 330.0 PF
50V 5%
Ref. Des. Part Number Description
