Motorola APX 2000 Detailed Service Manual

8-304 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01)
C427M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C428M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C429M20 2113944A31 CAP CER CHP 33.0PF 50V
5%
C430M20 2115153H44 CAP, CERAMIC, COG
C431M20 2113944A31 CAP CER CHP 33.0PF 50V
5%
C432M20 2115153H20 CAP, CERAMIC, COG
C433M20 2113944A63 CAP,FXD,1PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,P
C434M20 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C484M20 2115153H03 CAP, CERAMIC, COG
C485M20 2113944A63 CAP,FXD,1PF,.25PF+/-,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,P
C487M20 2113944A31 CAP CER CHP 33.0PF 50V
5%
C488M20 2113944V13 CAP,FXD,2.7PF,.1PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C490M20 2113944V07 CAP,FXD,1.5PF,.1PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C492M20 2113944V13 CAP,FXD,2.7PF,.1PF+/-
,50V-DC,0402,C0G,-55DEG
CMIN,125DEG CMAX
C500M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C501M21 2113944A32 CAP CER CHP 39.0PF 50V
5%
C502M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
Ref. Des. Part Number Description
C504M21 2113944A70 CAP,FXD,6PF,.5PF+/-,50V-
DC,0402,C0G,-55DEG
CMIN,125DEG CMAX,PB
C505M21 NOTPLACED –
C506M21 2113944A32 CAP CER CHP 39.0PF 50V
5%
C507M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C508M21 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C509M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C510M21 2113944A32 CAP CER CHP 39.0PF 50V
5%
C511M21 2113945B05 CAP,FXD,.033UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C512M21 2113946D07 CAP,CHIP,4.7UF,+10%,-
10%,6.3V-DC,0603,X5R,-
55DEG CMIN,85DEG CMA
C514M21 NOTPLACED –
C515M21 2113944A14 CAP CER CHP 3.6PF 50V
+/- 0.25PF
C516M21 2113944M30 CAP,FXD,33PF,+2%,-
2%,50V-DC,0603,C0G,-
55DEG CMIN,125DEG
CMAX,PB
C532M21 2113944A32 CAP CER CHP 39.0PF 50V
5%
C533M21 2115153H52 CAP, CERAMIC, COG
C550M21 NOTPLACED –
C551M21 NOTPLACED –
C601M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C602M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C603M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
Ref. Des. Part Number Description
C604M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C605M19 2113944A15 CAP CER CHP 3.9PF 50V
+/- 0.25PF
C606M19 2113946B04 CAP CER CHP 0.10UF 10V
10%
C607M19 2113944A40 CAP CER CHP 100.0PF
50V 5%
C608M19 2113944A12 CAP CER CHP 3.0PF 50V
+/- 0.25PF
C609M19 2113944A30 CAP CER CHP 27.0PF 50V
5%
C6104M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6105M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6106M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6107M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6108M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6109M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C610M19 2113944A40 CAP CER CHP 100.0PF
50V 5%
C6110M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6111M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6112M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6113M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6114M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6115M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C611M19 2113944A40 CAP CER CHP 100.0PF
50V 5%
Ref. Des. Part Number Description
C612M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C613M19 2113944A40 CAP CER CHP 100.0PF
50V 5%
C614M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C6155M6 NOTPLACED –
C6156M6 NOTPLACED –
C615M19 2113944A42 CAP CER CHP 150.0PF
50V 5%
C616M19 2113945A11 CAP CER CHP 2200PF 50V
10%
C617M19 2113946B04 CAP CER CHP 0.10UF 10V
10%
C618M19 2113944A31 CAP CER CHP 33.0PF 50V
5%
C619M19 2113944A35 CAP CER CHP 62.0PF 50V
5%
C6201M6 2113944A40 CAP CER CHP 100.0PF
50V 5%
C6202M6 2113945A09 CAP CER CHP 1000PF 50V
10%
C6203M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C620M19 2113946B04 CAP CER CHP 0.10UF 10V
10%
C621M19 2113946B04 CAP CER CHP 0.10UF 10V
10%
C622M19 2113946C07 CAP,FXD,.33UF,+10%,-
10%,10V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C623M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C624M19 2113946C07 CAP,FXD,.33UF,+10%,-
10%,10V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C625M19 2115153H39 CAP, CERAMIC, COG
C626M19 2113945A09 CAP CER CHP 1000PF 50V
10%
C627M19 2113945A09 CAP CER CHP 1000PF 50V
10%
Ref. Des. Part Number Description
