Motorola APX 2000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01) 8-305
C628M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C629M19 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6301M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6302M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6303M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6304M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6305M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6306M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6308M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6309M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C630M19 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6310M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6311M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C631M19 2115153H31 CAP, CERAMIC, COG
C632M19 2113944A40 CAP CER CHP 100.0PF
50V 5%
C633M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C634M19 2113946B04 CAP CER CHP 0.10UF 10V
10%
C635M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C636M19 2113946B04 CAP CER CHP 0.10UF 10V
10%
C637M19 2113946B04 CAP CER CHP 0.10UF 10V
10%
C638M19 2113945A12 CAP CER CHP 3300PF 50V
10%
Ref. Des. Part Number Description
C639M19 2113945B02 CAP CER CHP 10,000PF
25V 10%
C6401M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6402M6 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6403M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6404M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6405M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6406M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6407M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6408M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6409M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C640M19 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6410M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6411M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6412M6 NOTPLACED –
C6413M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6414M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6415M6 NOTPLACED –
C6416M6 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C6417M6 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C6418M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
Ref. Des. Part Number Description
C6419M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C641M19 2113944A31 CAP CER CHP 33.0PF 50V
5%
C6420M6 2113945B04 CAP,FXD,.022UF,+10%,-
10%,25V-DC,0402,X7R,-
55DEG CMIN,125DEG CMA
C6421M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6422M6 2113946C02 CAP CER CHP 0.22UF 10V
10%
C6423M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6424M6 2113944A40 CAP CER CHP 100.0PF
50V 5%
C6425M6 2113944A40 CAP CER CHP 100.0PF
50V 5%
C6426M6 2113945B02 CAP CER CHP 10,000PF
25V 10%
C6427M6 2113944A50 CAP CER CHP 680.0 PF
50V 5%
C6428M6 2113944A40 CAP CER CHP 100.0PF
50V 5%
C6429M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C642M19 2113944A48 CAP CER CHP 470.0 PF
50V 5%
C6430M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6431M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6432M6 2113956B54 CAP,FXD,10UF,+20%,-
20%,6.3V-DC,X5R,-55DEG
CMIN,85DEG CMAX,PB-F
C6433M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6434M6 2113946L05 CAP,FXD,.33UF,+80%,-
20%,16V-DC,0603,Y5V,-
30DEG CMIN,85DEG CMAX
C6435M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
Ref. Des. Part Number Description
C6436M6 2113946C08 CAP,FXD,.47UF,+10%,-
10%,10V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6437M6 2113946C08 CAP,FXD,.47UF,+10%,-
10%,10V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6438M6 2113944A40 CAP CER CHP 100.0PF
50V 5%
C643M19 2113944A48 CAP CER CHP 470.0 PF
50V 5%
C644M19 2113944A11 CAP CER CHP 2.7PF 50V
+/- 0.25PF
C645M19 NOTPLACED –
C646M19 2115153H32 CAP, CERAMIC, COG
C6501M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6502M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6503M6 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C6504M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6505M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6506M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6507M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6508M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6509M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6510M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6511M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6512M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6513M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
Ref. Des. Part Number Description
