Motorola APX 2000 Detailed Service Manual

8-306 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01)
C6514M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6515M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6516M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6517M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6518M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6519M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6520M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6521M6 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C6522M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6523M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6524M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6525M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6526M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6527M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6528M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6529M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6530M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6531M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6532M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6533M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
Ref. Des. Part Number Description
C6534M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6535M6 2113944A40 CAP CER CHP 100.0PF
50V 5%
C6536M6 2113944A28 CAP CER CHP 18.0PF 50V
5%
C6537M6 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C6538M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6539M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6540M6 2113945A09 CAP CER CHP 1000PF 50V
10%
C6541M6 2113944A19 CAP CER CHP 5.6PF 50V
+/- 0.5PF
C6542M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6543M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6544M6 2113945D04 CAP CER CHP 100,000PF
25V 10%
C6545M6 2113945D04 CAP CER CHP 100,000PF
25V 10%
C6546M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6547M6 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C6548M6 NOTPLACED –
C6549M6 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C6550M6 2113945D04 CAP CER CHP 100,000PF
25V 10%
C6551M6 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C6552M6 2113956E91 CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X5R,-
55DEG CMIN,85DEG
CMAX,P
Ref. Des. Part Number Description
C6553M6 2113956E91 CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6554M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6555M6 2113955D45 CAP,FXD,4.7UF,+10%,-
10%,10V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C6556M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6557M6 2113945D04 CAP CER CHP 100,000PF
25V 10%
C6558M6 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C6559M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6560M6 2113956C37 CAP,FXD,10UF,+10%,-
10%,16V-DC,0805,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6561M6 2113956C37 CAP,FXD,10UF,+10%,-
10%,16V-DC,0805,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6562M6 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5PF
C6563M6 2113945D04 CAP CER CHP 100,000PF
25V 10%
C6564M6 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C6565M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6566M6 2113956E91 CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6567M6 2113956E91 CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X5R,-
55DEG CMIN,85DEG
CMAX,P
Ref. Des. Part Number Description
C6568M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6569M6 2113956E91 CAP,FXD,10UF,+10%,-
10%,16V-DC,1210,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6570M6 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C6571M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6572M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6573M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6574M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6575M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6576M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6577M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6578M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6579M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6580M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6581M6 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6582M6 2113944A21 CAP CER CHP 6.8PF 50V
+/- 0.5PF
C6583M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6584M6 2113956C37 CAP,FXD,10UF,+10%,-
10%,16V-DC,0805,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6585M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
Ref. Des. Part Number Description
