Motorola APX 2000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01) 8-307
C6586M6 2113956C35 CAP,FXD,4.7UF,+10%,-
10%,16V-DC,0805,X5R,-
55DEG CMIN,85DEG CMAX
C6587M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6588M6 2113944A46 CAP CER CHP 330.0 PF
50V 5%
C6589M6 2113944A40 CAP CER CHP 100.0PF
50V 5%
C6590M6 2113946B04 CAP CER CHP 0.10UF 10V
10%
C6591M6 2113944A28 CAP CER CHP 18.0PF 50V
5%
C6592M6 2113944A09 CAP CER CHP 2.2PF 50V
+/- 0.25PF
C6593M6 2113956C37 CAP,FXD,10UF,+10%,-
10%,16V-DC,0805,X5R,-
55DEG CMIN,85DEG
CMAX,P
C6594M6 2113946C07 CAP,FXD,.33UF,+10%,-
10%,10V-DC,0603,X5R,-
55DEG CMIN,85DEG CMAX
C6595M6 2113946S35 CAP CER CHP 1.0UF 16V
10%
C6596M6 NOTPLACED –
C6601M6 2113944A28 CAP CER CHP 18.0PF 50V
5%
C6602M6 2113944A28 CAP CER CHP 18.0PF 50V
5%
C6670M6 NOTPLACED –
C702M7 2185419D06 CAP CER SUPER L/D
0.1UF
C703M7 2113945C26 CAP,FXD,.039UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG CMA
C704M7 2185419D06 CAP CER SUPER L/D
0.1UF
C705M7 2115153H30 CAP, CERAMIC, COG
C706M7 2185419D06 CAP CER SUPER L/D
0.1UF
C707M7 2113945C01 CAP CER CHP 6800PF 50V
10%
Ref. Des. Part Number Description
C708M7 NOTPLACED –
C709M7 2185419D06 CAP CER SUPER L/D
0.1UF
C710M7 NOTPLACED –
C711M7 NOTPLACED –
C712M7 NOTPLACED –
C713M7 2113945C25 CAP,FXD,.033UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG CMA
C714M7 2185419D06 CAP CER SUPER L/D
0.1UF
C715M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C716M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C717M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C718M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C719M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C720M7 2113944C55 CAP CER CHP 1200.OPF
50V 5%
C721M7 NOTPLACED –
C724M7 2113955D37 CAP,FXD,10UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C725M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
C726M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C727M7 2113944A40 CAP CER CHP 100.0PF
50V 5%
C730M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C731M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C732M7 2113944A32 CAP CER CHP 39.0PF 50V
5%
C733M7 2113945A09 CAP CER CHP 1000PF 50V
10%
C734M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C735M7 2113944A31 CAP CER CHP 33.0PF 50V
5%
C736M7 2113945B02 CAP CER CHP 10,000PF
25V 10%
C737M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C739M7 2113944A17 CAP CER CHP 4.7PF 50V
+/- 0.25PF
C740M7 2115153H45 CAP, CERAMIC, COG
C742M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C743M7 2113946B06 CAP,CHIP,.22UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C744M7 2113955D37 CAP,FXD,10UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
C749M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C750M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C751M7 2113945A09 CAP CER CHP 1000PF 50V
10%
C752M7 2113944A43 CAP CER CHP 180.0PF
50V 5%
C753M7 2113944A31 CAP CER CHP 33.0PF 50V
5%
C754M7 2113944A34 CAP CER CHP 56.0PF 50V
5%
C756M7 2113955D37 CAP,FXD,10UF,+10%,-
10%,16V-DC,1206,X7R,-
55DEG CMIN,125DEG
CMAX
C757M7 2113945C31 CAP,FXD,.1UF,+10%,-
10%,50V-DC,0603,X7R,-
55DEG CMIN,125DEG
CMAX
C760M7 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C764M7 2113946B06 CAP,CHIP,.22UF,+10%,-
10%,10V-DC,0402,X5R,-
55DEG CMIN,85DEG CMAX
C770M7 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C772M7 2113945A09 CAP CER CHP 1000PF 50V
10%
C773M7 2113944A33 CAP CER CHP 47.0PF 50V
5%
C777M7 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C780M7 2113944A33 CAP CER CHP 47.0PF 50V
5%
C781M7 2115153H45 CAP, CERAMIC, COG
C786M7 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C803M7 2115153H45 CAP, CERAMIC, COG
Ref. Des. Part Number Description

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
