Motorola APX 2000 Detailed Service Manual

8-308 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01)
C813M7 NOTPLACED –
C816M7 2113944A30 CAP CER CHP 27.0PF 50V
5%
C817M7 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C819M7 2113944A44 CAP CER CHP 220.0 PF
50V 5%
C823M7 2113944A40 CAP CER CHP 100.0PF
50V 5%
C824M7 2115153H45 CAP, CERAMIC, COG
D200M12 4813978A19 DIODE,RECT,MBR120,SM,
SOD-123,1A,20V,SHTK,PB-
FREE
D2101M2 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D2301M13 4813974A19 DIODE
ARRAY,MXR,SM,SOT-
323,7V,.2W,SHTK,2,PB-
FREE
D2302M13 4815897H01 PIN DIODE
D2303M13 4815897H01 PIN DIODE
D4001M2 4813978A25 SCHOTTKY 30V SOD-323
T&R PB FREE
D401M20 NOTPLACED –
D6101M6 4813978A25 SCHOTTKY 30V SOD-323
T&R PB FREE
D6401M6 4813978A25 SCHOTTKY 30V SOD-323
T&R PB FREE
D6501M6 4813978A25 SCHOTTKY 30V SOD-323
T&R PB FREE
D6502M6 4813978A25 SCHOTTKY 30V SOD-323
T&R PB FREE
D722M7 4815011H01 DIODE TRIPLE
D723M7 4815011H01 DIODE TRIPLE
E1101M11 2405688Z01 INDUCTOR FERRITE BEAD
E201M12 7686949J14 FLTR,FERRITE
BEAD,,2A,,,SM,0805,CHIP,2
20OHM
E2242M2 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
Ref. Des. Part Number Description
E2244M2 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
E2245M2 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
E2246M2 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
E2247M2 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
E2248M2 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
E2249M2 7685268E01 FERRITE BEAD 20X40 200
MA MAX CHIP
E2301M2 91012036001 FILTER,EMI/
RFI,300MA,SM,0402,PB
FREE
E2302M2 91012036001 FILTER,EMI/
RFI,300MA,SM,0402,PB
FREE
E2303M2 91012036001 FILTER,EMI/
RFI,300MA,SM,0402,PB
FREE
E2304M2 91012036001 FILTER,EMI/
RFI,300MA,SM,0402,PB
FREE
E2305M2 91012036001 FILTER,EMI/
RFI,300MA,SM,0402,PB
FREE
E2306M2 91012036001 FILTER,EMI/
RFI,300MA,SM,0402,PB
FREE
E2307M2 91012036001 FILTER,EMI/
RFI,300MA,SM,0402,PB
FREE
E2308M2 91012036001 FILTER,EMI/
RFI,300MA,SM,0402,PB
FREE
E2309M2 91012036001 FILTER,EMI/
RFI,300MA,SM,0402,PB
FREE
E2310M2 91012036001 FILTER,EMI/
RFI,300MA,SM,0402,PB
FREE
Ref. Des. Part Number Description
E2311M2 91012036001 FILTER,EMI/
RFI,300MA,SM,0402,PB
FREE
E401M20 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E402M20 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E601M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E602M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E603M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E604M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E605M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E606M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E607M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E608M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E609M19 2480640Z01 SURFACE MOUNT FER-
RITE BEAD
E6501M6 2480067M02 CHK RF CHIP BEAD
INDUCTOR
E6502M6 2480067M02 CHK RF CHIP BEAD
INDUCTOR
F200M12 6575834B01 FUSE SURFACE MOUNT
FL1301M3 9102190J23 FLTR,SAW,BAND-
PASS,1.57542GHZ
NOM,SM,1.4X1.0MM,SMD,
PB-FREE
FL1302M3 9109674L58 PASSIVE FIL-
TER,CER,BAND-
PASS,2.45GHZ NOM
FL1303M3 9102190J23 FLTR,SAW,BAND-
PASS,1.57542GHZ
NOM,SM,1.4X1.0MM,SMD,
PB-FREE
FL401M20 9175390A01 SAW FILTER, DUAL BAND
769/860.5
Ref. Des. Part Number Description
FL402M20 9175390A01 SAW FILTER, DUAL BAND
769/860.5
FL502M21 91009300001 FILTER,MONOLITHIC
CRYSTAL,BAND-
PASS,109.65MHZ NOM
J102M12 2880658Z08 CONNECTOR SMA
J2301M2 0970312N01 CONN,BTB,RCPT,60CONT,.
4MM,GLD,1 STACK HGT
J2302M2 0970312N01 CONN,BTB,RCPT,60CONT,.
4MM,GLD,1 STACK HGT
L1001M16 2415429H37 CHIP INDUCTOR
L1002M16 2415429H10 CHIP INDUCTOR
L1003M16 2415429H37 CHIP INDUCTOR
L1007M16 2460591K40 COIL AIR WOUND INDUC
59.71
L1009M16 2415428H03 AIR WOUND INDUCTOR
L1101M11 2415429H26 CHIP INDUCTOR
L1102M11 2415429H10 CHIP INDUCTOR
L1116M11 NOTPLACED –
L1117M11 2415428H02 AIR WOUND INDUCTOR
L1301M3 2414017P16 IDCTR,CHIP,18NH,5%,300
MA,.76OHM,CER,9
Q,1.9GHZ SRF,SM,0402,P
L1302M3 2488090Y07 INDUCTOR,MULTI-
LAYER,3.3NH,1005,SMD,P
B FREE
L1303M3 2414017P16 IDCTR,CHIP,18NH,5%,300
MA,.76OHM,CER,9
Q,1.9GHZ SRF,SM,0402,P
L1304M3 2488090Y25 INDUCTOR,MULTI-
LAYER,100NH,1005,SMD,P
B FREE
L1305M3 24010062002 INDUCTOR, 5.6NH, 0402,
2%
L1306M3 2414017P14 IDCTR,CHIP,12NH,5%,300
MA,.6OHM,CER,9 Q,2GHZ
SRF,SM,0402,PB-F
L1308M3 NOTPLACED –
L1316M3 24010062009 INDUCTOR, 13NH, 0402,
2%
Ref. Des. Part Number Description
