Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01) 8-309
L1408M17 24012026009 ULTRA-MINIATURE AIR
CORE INDUCTORS
L1410M17 24012026009 ULTRA-MINIATURE AIR
CORE INDUCTORS
L200M12 2571269C01 INDUCTOR WW POWER
20%
L2202M2 2415429H45 CHIP INDUCTOR
L2203M2 2415429H45 CHIP INDUCTOR
L2204M2 2415429H45 CHIP INDUCTOR
L2205M2 2415429H45 CHIP INDUCTOR
L2301M13 24012026009 ULTRA-MINIATURE AIR
CORE INDUCTORS
L2302M13 2415429H35 CHIP INDUCTOR
L2303M13 2414017N14 IDCTR,CHIP,15NH,5%,600
MA,.4OHM,CER,12
Q,1.8GHZ SRF,SM,0603,P
L3008M22 2414032F36 IDCTR,WW,150NH,5%,400
MA,.56OHM,CER,35
Q,780MHZ SRF,SM,PB-FR
L3009M22 2414032F36 IDCTR,WW,150NH,5%,400
MA,.56OHM,CER,35
Q,780MHZ SRF,SM,PB-FR
L3041M22 2414032F36 IDCTR,WW,150NH,5%,400
MA,.56OHM,CER,35
Q,780MHZ SRF,SM,PB-FR
L3044M22 2414032F36 IDCTR,WW,150NH,5%,400
MA,.56OHM,CER,35
Q,780MHZ SRF,SM,PB-FR
L3047M22 2414032F36 IDCTR,WW,150NH,5%,400
MA,.56OHM,CER,35
Q,780MHZ SRF,SM,PB-FR
L3064M22 2414032F36 IDCTR,WW,150NH,5%,400
MA,.56OHM,CER,35
Q,780MHZ SRF,SM,PB-FR
L401M20 2415427H21 CHIP INDUCTOR
L402M20 2415427H23 CHIP INDUCTOR
L403M20 2414017P07 IDCTR,CHIP,3.3NH,300MA,.
19OHM,CER,8 Q,4GHZ
SRF,SM,0402,PB-F
L404M20 2415427H26 CHIP INDUCTOR
L405M20 2415427H21 CHIP INDUCTOR
Ref. Des. Part Number Description
L406M20 2415427H05 CHIP INDUCTOR
L407M20 2415427H16 CHIP INDUCTOR
L408M20 2415427H21 CHIP INDUCTOR
L489M20 2478057A14 8.2NH SURFACE MOUNT
INDUCTOR
L491M20 2478057A14 8.2NH SURFACE MOUNT
INDUCTOR
L500M21 2415429H43 CHIP INDUCTOR
L503M21 2414017N24 IDCTR,CHIP,100NH,5%,300
MA,2OHM,CER,14
Q,700MHZ SRF,SM,0603,P
L504M21 2478057A51 0306 HIGH Q CHIP INDUC-
TOR
L513M21 NOTPLACED –
L550M21 2414017N10 IDCTR,CHIP,6.8NH,5%,600
MA,.22OHM,CER,10
Q,2.7GHZ SRF,SM,0603
L601M19 2415429H43 CHIP INDUCTOR
L602M19 2466505A01 COIL INDUCTOR
L603M19 2466505A01 COIL INDUCTOR
L604M19 2414032D16 IDCTR,WW,120NH,5%,800
MA,.26OHM,CER,42
Q,1GHZ SRF,SM,PB-FREE
L605M19 24012050001 0603LS CHIP INDUC-
TORS, 1608, 3900NH
L611M19 2414032F39 IDCTR,WW,270NH,10%,280
MA,1OHM,CER,40
Q,800MHZ SRF,SM,PB-FRE
L6401M6 2471189M03 SHIELDED SMT POWER
INDUCTOR 10UH
L6402M6 2471189M03 SHIELDED SMT POWER
INDUCTOR 10UH
L6403M6 24009271001 20NH HIGH CURRENT
CHIP INDUCTOR
L6404M6 24009271001 20NH HIGH CURRENT
CHIP INDUCTOR
L6502M6 2471678H01 10UH INDCUTOR
L6504M6 24009268001 10UH 2.1A SHIELDED
INDUCTOR
L6505M6 2471678H01 10UH INDCUTOR
Ref. Des. Part Number Description
L701M7 2488090Y17 INDUCTOR,MULTI-
LAYER,22NH,1005,SMD,PB
FREE
L709M7 2414017N16 IDCTR,CHIP,22NH,5%,600
MA,.54OHM,CER,12
Q,1.3GHZ SRF,SM,0603
L720M7 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L727M7 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L728M7 2415429H47 CHIP INDUCTOR
L733M7 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L735M7 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L738M7 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L739M7 2414017N25 IDCTR,CHIP,120NH,5%,200
MA,2.4OHM,CER,12
Q,600MHZ SRF,SM,0603
L741M7 2480646Z20 COIL MULTI-LAYER
CHIP(2.20UH)
L753M7 2415347H06 IDCTR, 2200NH
L755M7 2415429H38 CHIP INDUCTOR
L758M7 2415429H47 CHIP INDUCTOR
L759M7 2414017N25 IDCTR,CHIP,120NH,5%,200
MA,2.4OHM,CER,12
Q,600MHZ SRF,SM,0603
L768M7 2488090Y25 INDUCTOR,MULTI-
LAYER,100NH,1005,SMD,P
B FREE
L775M7 2415429H38 CHIP INDUCTOR
M101M12 39012039001 CONNECTOR, BATTERY
CONTACT
M103M12 3987977Y04 CONT,CONN,1CONT,,ANT
UNIV 4.5MM,UC 1.8
M104M12 3987977Y04 CONT,CONN,1CONT,,ANT
UNIV 4.5MM,UC 1.8
M105M12 3987977Y04 CONT,CONN,1CONT,,ANT
UNIV 4.5MM,UC 1.8
Ref. Des. Part Number Description
M1301M3 3987977Y01 CONTACT ANTENNA UNI-
VERSAL (D35)
M6405M6 3987977Y04 CONT,CONN,1CONT,,ANT
UNIV 4.5MM,UC 1.8
M6406M6 3987977Y04 CONT,CONN,1CONT,,ANT
UNIV 4.5MM,UC 1.8
M6502M6 0985888K02 SKT RTC BTTY LEAP
M6504M6 3987977Y04 CONT,CONN,1CONT,,ANT
UNIV 4.5MM,UC 1.8
PCB 84012266001 BOARD, PC , MAIN BOARD
Q1001M16 48012094001 MOD,XSTR,FET RF PWR,
135-941MHZ
Q1101M11 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,
PB-FREE
Q1103M11 4813970A59 P-CH FET 1.0A 20V SOT-23
T&R
Q201M12 4813970A59 P-CH FET 1.0A 20V SOT-23
T&R
Q202M12 4813973A32 XSTR,BIP GP
SS,NPN,SM,SC-
70,SMT,50V,.202W,100MA,
PB-FREE
Q2202M2 4815261H01 TRANSISTOR,BIP GEN-
ERAL PURPOSE SMALL
NPN
Q2301M13 4815055H01 TSTR DUAL NPN/PNP UMH
5
Q3033M22 4813972A17 PB-FREE,NOT COM-
PLETELY ENRICHED
Q3035M22 4813972A17 PB-FREE,NOT COM-
PLETELY ENRICHED
Q3038M22 4871915M01 XSTR,BIP RF SML
SGNL,NPN,SM,4.5GHZ
Q3039M22 4871915M01 XSTR,BIP RF SML
SGNL,NPN,SM,4.5GHZ
Q3060M22 4813972A17 PB-FREE,NOT COM-
PLETELY ENRICHED
Q3062M22 4871915M01 XSTR,BIP RF SML
SGNL,NPN,SM,4.5GHZ
Ref. Des. Part Number Description
