8-310 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01)

Q4001M2 4815261H01 TRANSISTOR,BIP GEN-

ERAL PURPOSE SMALL

NPN

Q401M20 4813973A32 XSTR,BIP GP

SS,NPN,SM,SC-

70,SMT,50V,.202W,100MA,

PB-FREE

Q402M20 4813973M75 XSTR,BIP GP

SS,PNP,BC858,SOT-

563,SMT,-30V,.357W,-

100MA,100MHZ

Q403M20 4813973M75 XSTR,BIP GP

SS,PNP,BC858,SOT-

563,SMT,-30V,.357W,-

100MA,100MHZ

Q601M19 4813973A04 XSTR,BIP GP

SS,NPN,TA13,SM,SOT-

23,SMT,30V,.225W,300MA,1

25MHZ,P

Q6101M6 4815261H01 TRANSISTOR,BIP GEN-

ERAL PURPOSE SMALL

NPN

Q6401M6 48012170001 FET

Q6501M6 4813970A62 XSTR,FET GP PWR,MOS-

FET,P-CH,ENHN,CF,-

20V,1.3W,PB-FREE

Q6502M6 48012154001 FET

Q6504M6 4809579E77 FET, NCH MOS FET, 1.2MM

X 1.2MM PACKAGE, SMD,

W18 COMPLIANT

Q6505M6 4813970A62 XSTR,FET GP PWR,MOS-

FET,P-CH,ENHN,CF,-

20V,1.3W,PB-FREE

Q6506M6 4809579E77 FET, NCH MOS FET, 1.2MM

X 1.2MM PACKAGE, SMD,

W18 COMPLIANT

Q6507M6 48012170001 FET

Q6508M6 48012154001 FET

Q731M7 4885061Y01 XSTR NPN 6V 30UA 12GHZ

PB-FREE

Q745M7 4813973M75 XSTR,BIP GP

SS,PNP,BC858,SOT-

563,SMT,-30V,.357W,-

100MA,100MHZ

Ref. Des. Part Number Description

Q756M7 4805585Q32 TRANSITOR, NPN RF

Q767M7 4813973M75 XSTR,BIP GP

SS,PNP,BC858,SOT-

563,SMT,-30V,.357W,-

100MA,100MHZ

Q774M7 4805585Q32 TRANSITOR, NPN RF

Q785M7 4889394V04 XSTR,FET GEN PURPOSE

SMALL SIG,MOSFET,N-

CH,ENHN,SM,20V,.25W,P

R1001M16 0613952R13 CER CHIP RES 33K OHM

5% 0402

R1002M16 0613952R17 CER CHIP RES 47K OHM

5% 0402

R1003M16 0613952R21 CER CHIP RES 68K OHM

5% 0402

R1004M16 0613952R12 CER CHIP RES 30K OHM 5

0402

R1005M16 0613952Q73 CER CHIP RES 1000 OHM

5 0402

R1006M16 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R1007M16 0613952H53 CER CHIP RES 150 OHM

5% 0603

R1064M16 NOTPLACED –

R1065M16 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R1066M16 NOTPLACED –

R1101M11 0613952R01 CER CHIP RES 10K OHM

5% 0402

R1102M11 0613952R25 CER CHIP RES 100K OHM

5% 0402

R1103M11 6009259001 LOW RESISTANCE THICK

FILM RESISTOR

R1104M11 0613952Q49 CER CHIP RES 100 OHM 5

0402

R1105M11 0613952Q49 CER CHIP RES 100 OHM 5

0402

R1106M11 0613952Q21 CER CHIP RES 6.8 OHM 5

0402

R1107M11 0613952Q45 CER CHIP RES 68.0 OHM 5

0402

Ref. Des. Part Number Description

R1108M11 0613952N81 CER CHIP RES 68.1K OHM

1 0402

R1110M11 0613952R01 CER CHIP RES 10K OHM

5% 0402

R1111M11 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R1112M11 NOTPLACED –

R1114M11 0613952Q49 CER CHIP RES 100 OHM 5

0402

R1115M11 0613952Q49 CER CHIP RES 100 OHM 5

0402

R1116M11 0613952R01 CER CHIP RES 10K OHM

5% 0402

R1117M11 0613952R22 CER CHIP RES 75K OHM 5

0402

R1121M11 0613952N47 CER CHIP RES 30.1K OHM

1 0402

R1122M11 0613952N85 CER CHIP RES 75.0K OHM

1 0402

R1124M11 0613952Q42 CER CHIP RES 51.0 OHM 5

0402

R1125M11 0613952R10 CER CHIP RES 24K OHM 5

0402

R1126M11 0613952R02 CER CHIP RES 11K OHM 5

0402

R1127M11 0613952R08 CER CHIP RES 20K OHM 5

0402

R1128M11 0613952R01 CER CHIP RES 10K OHM

5% 0402

R1129M11 NOTPLACED –

R1130M11 NOTPLACED –

R1135M11 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R1136M11 0613952R01 CER CHIP RES 10K OHM

5% 0402

R1137M11 0613952R01 CER CHIP RES 10K OHM

5% 0402

R1138M11 0613952R25 CER CHIP RES 100K OHM

5% 0402

R1139M11 0613952R25 CER CHIP RES 100K OHM

5% 0402

Ref. Des. Part Number Description

R1140M11 0613952R25 CER CHIP RES 100K OHM

5% 0402

R1141M11 0613952R42 CER CHIP RES 510K OHM

5 0402

R1142M11 0613952R25 CER CHIP RES 100K OHM

5% 0402

R1143M11 0613952R25 CER CHIP RES 100K OHM

5% 0402

R1144M11 0613952R25 CER CHIP RES 100K OHM

5% 0402

R1145M11 0613952R25 CER CHIP RES 100K OHM

5% 0402

R1146M11 0613952R25 CER CHIP RES 100K OHM

5% 0402

R1151M11 0613952R01 CER CHIP RES 10K OHM

5% 0402

R1152M11 0613952R01 CER CHIP RES 10K OHM

5% 0402

R1154M11 0613952N01 CER CHIP RES 10.0K OHM

1 0402

R1158M11 NOTPLACED –

R1160M11 0613952R03 CER CHIP RES 12K OHM

5% 0402

R1162M11 0613952R29 CER CHIP RES 150K OHM

5% 0402

R1163M11 0613952R01 CER CHIP RES 10K OHM

5% 0402

R1164M11 0613952R01 CER CHIP RES 10K OHM

5% 0402

R1165M11 0613952Q56 CER CHIP RES 200 OHM 5

0402

R1166M11 0613952Q56 CER CHIP RES 200 OHM 5

0402

R1167M11 0613952R01 CER CHIP RES 10K OHM

5% 0402

R1168M11 0613952Q49 CER CHIP RES 100 OHM 5

0402

R1169M11 0613952P52 CER CHIP RES 340K OHM

1 0402

R1170M11 0613952N88 CER CHIP RES 80.6K OHM

1 0402

Ref. Des. Part Number Description

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)

Motorola APX 2000 Detailed Service Manual
