Motorola APX 2000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01) 8-311
R1171M11 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1172M11 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R1174M11 0613952N01 CER CHIP RES 10.0K OHM
1 0402
R1175M11 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1176M11 0613952M01 CER CHIP RES 1000 OHM
1% 0402
R1177M11 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1178M11 0613952R01 CER CHIP RES 10K OHM
5% 0402
R1180M11 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1181M11 NOTPLACED –
R1182M11 0613952R01 CER CHIP RES 10K OHM
5% 0402
R1198M11 0613952J01 CER CHIP RES 10K OHM
5% 0603
R1301M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1303M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1305M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1309M3 NOTPLACED –
R1310M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1311M3 NOTPLACED –
R1313M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1315M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1317M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1318M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1325M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
Ref. Des. Part Number Description
R1326M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1329M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1330M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1331M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1332M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R1337M3 NOTPLACED –
R1339M3 NOTPLACED –
R1340M3 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R201M12 0613952R25 CER CHIP RES 100K OHM
5% 0402
R202M12 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R21000M2 NOTPLACED –
R21001M2 NOTPLACED –
R21002M2 NOTPLACED –
R21003M2 NOTPLACED –
R2104M2 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R2105M2 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R2106M2 NOTPLACED –
R2107M2 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R2109M2 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R2110M2 0613952Q33 CER CHIP RES 22.0 OHM 5
0402
R2111M2 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R2113M2 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R2114M2 0613952Q33 CER CHIP RES 22.0 OHM 5
0402
Ref. Des. Part Number Description
R2115M2 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R2116M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2117M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2118M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2120M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2129M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2130M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2131M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2132M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2133M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2135M2 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R2136M2 0613952Q61 CER CHIP RES 330 OHM 5
0402
R2137M2 0613952Q61 CER CHIP RES 330 OHM 5
0402
R2138M2 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R2139M2 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R2142M2 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R2144M2 0613952Q61 CER CHIP RES 330 OHM 5
0402
R2145M2 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R2146M2 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R2147M2 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
Ref. Des. Part Number Description
R2148M2 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R2149M2 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R2151M2 NOTPLACED –
R2153M2 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R2154M2 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R2192M2 0613952Q61 CER CHIP RES 330 OHM 5
0402
R2197M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2198M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2199M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2201M2 0613952R32 CER CHIP RES 200K OHM
5 0402
R2204M2 0613952Q85 CER CHIP RES 3300 OHM
5 0402
R2206M2 0613952Q85 CER CHIP RES 3300 OHM
5 0402
R2207M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2235M2 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R2244M2 0613952Q65 CER CHIP RES 470 OHM 5
0402
R2245M2 0613952Q60 CER CHIP RES 300 OHM 5
0402
R2246M2 0613952Q65 CER CHIP RES 470 OHM 5
0402
R2254M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2301M13 NOTPLACED –
R2302M13 0613952H47 CER CHIP RES 82.0 OHM 5
0603
R2303M13 0613952H47 CER CHIP RES 82.0 OHM 5
0603
Ref. Des. Part Number Description

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
