Motorola APX 2000 Detailed Service Manual

8-312 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01)
R2304M13 0613952H47 CER CHIP RES 82.0 OHM 5
0603
R2305M13 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R2306M13 0613952R25 CER CHIP RES 100K OHM
5% 0402
R2803M1 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R2804M1 0613952Q49 CER CHIP RES 100 OHM 5
0402
R2805M1 0613952Q49 CER CHIP RES 100 OHM 5
0402
R2806M1 0613952Q59 CER CHIP RES 270 OHM 5
0402
R2807M1 0613952Q56 CER CHIP RES 200 OHM 5
0402
R2808M1 0613952Q49 CER CHIP RES 100 OHM 5
0402
R2810M1 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2811M1 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R2812M1 0613952R01 CER CHIP RES 10K OHM
5% 0402
R2813M1 NOTPLACED –
R2817M1 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R3018M22 0613952R18 CER CHIP RES 51K OHM 5
0402
R3019M22 0613952R18 CER CHIP RES 51K OHM 5
0402
R3030M22 0613952R08 CER CHIP RES 20K OHM 5
0402
R3031M22 0613952R08 CER CHIP RES 20K OHM 5
0402
R3032M22 0613952Q22 CER CHIP RES 7.5 OHM 5
0402
R3034M22 0613952Q34 CER CHIP RES 24.0 OHM 5
0402
R3036M22 0613952R08 CER CHIP RES 20K OHM 5
0402
Ref. Des. Part Number Description
R3037M22 0613952R08 CER CHIP RES 20K OHM 5
0402
R3040M22 0613952Q52 CER CHIP RES 130 OHM 5
0402
R3043M22 0613952Q46 CER CHIP RES 75.0 OHM 5
0402
R3052M22 0613952R18 CER CHIP RES 51K OHM 5
0402
R3058M22 0613952R07 CER CHIP RES 18K OHM
5% 0402
R3059M22 0613952Q27 CER CHIP RES 12.0 OHM 5
0402
R3061M22 0613952R08 CER CHIP RES 20K OHM 5
0402
R3063M22 0613952Q50 CER CHIP RES 110 OHM 5
0402
R3066M22 0613952Q32 CER CHIP RES 20.0 OHM 5
0402
R4005M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R4006M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R4007M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R4008M2 0613952R01 CER CHIP RES 10K OHM
5% 0402
R4009M2 0613952Q85 CER CHIP RES 3300 OHM
5 0402
R4010M2 0613952R32 CER CHIP RES 200K OHM
5 0402
R4011M2 0613952R17 CER CHIP RES 47K OHM
5% 0402
R4012M2 0613952R09 CER CHIP RES 22K OHM
5% 0402
R4013M2 0613952R09 CER CHIP RES 22K OHM
5% 0402
R4014M2 0613952Q85 CER CHIP RES 3300 OHM
5 0402
R401M20 0613952R09 CER CHIP RES 22K OHM
5% 0402
Ref. Des. Part Number Description
R402M20 0613952R23 CER CHIP RES 82K OHM
5% 0402
R403M20 0613952Q85 CER CHIP RES 3300 OHM
5 0402
R404M20 0613952Q45 CER CHIP RES 68.0 OHM 5
0402
R405M20 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R406M20 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R407M20 0613952R09 CER CHIP RES 22K OHM
5% 0402
R408M20 0613952R23 CER CHIP RES 82K OHM
5% 0402
R409M20 0613952Q85 CER CHIP RES 3300 OHM
5 0402
R410M20 0613952Q45 CER CHIP RES 68.0 OHM 5
0402
R411M20 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R412M20 0613952Q18 CER CHIP RES 5.1 OHM 5
0402
R413M20 0613952Q11 CER CHIP RES 2.7 OHM 5
0402
R447M20 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R448M20 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R450M20 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R451M20 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R452M20 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R453M20 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R454M20 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R455M20 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
Ref. Des. Part Number Description
R456M20 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R457M20 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R500M21 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R502M21 0613952Q36 CER CHIP RES 30.0 OHM 5
0402
R512M21 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R525M21 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R526M21 0613958J74 CER CHIP RES 0.0 OHM
JMP 0805
R601M19 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R602M19 0613952Q63 CER CHIP RES 390 OHM 5
0402
R603M19 0613952R25 CER CHIP RES 100K OHM
5% 0402
R604M19 0613952Q63 CER CHIP RES 390 OHM 5
0402
R605M19 0613952R01 CER CHIP RES 10K OHM
5% 0402
R606M19 0613952R01 CER CHIP RES 10K OHM
5% 0402
R607M19 0613952R25 CER CHIP RES 100K OHM
5% 0402
R608M19 0613952R01 CER CHIP RES 10K OHM
5% 0402
R609M19 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R6101M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6102M6 0613952R09 CER CHIP RES 22K OHM
5% 0402
R6103M6 0613952R09 CER CHIP RES 22K OHM
5% 0402
R6104M6 NOTPLACED –
R6105M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
Ref. Des. Part Number Description
