Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01) 8-313

R6106M6 0613952Q73 CER CHIP RES 1000 OHM

5 0402

R6107M6 0613952Q55 CER CHIP RES 180 OHM 5

0402

R6108M6 0613952Q61 CER CHIP RES 330 OHM 5

0402

R6109M6 NOTPLACED –

R610M19 0613952R25 CER CHIP RES 100K OHM

5% 0402

R6110M6 0613952Q73 CER CHIP RES 1000 OHM

5 0402

R6111M6 NOTPLACED –

R6112M6 NOTPLACED –

R6113M6 0613952Q51 CER CHIP RES 120 OHM 5

0402

R6114M6 0613952Q49 CER CHIP RES 100 OHM 5

0402

R6115M6 0613952Q49 CER CHIP RES 100 OHM 5

0402

R6116M6 0613952Q73 CER CHIP RES 1000 OHM

5 0402

R6117M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6118M6 0613952R09 CER CHIP RES 22K OHM

5% 0402

R6119M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R611M19 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6120M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6121M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6122M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6125M6 NOTPLACED –

R612M19 0613952Q94 CER CHIP RES 7500 OHM

5 0402

R613M19 0613952Q82 CER CHIP RES 2400 OHM

5 0402

Ref. Des. Part Number Description

R614M19 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R615M19 NOTPLACED –

R616M19 NOTPLACED –

R617M19 NOTPLACED –

R618M19 NOTPLACED –

R619M19 NOTPLACED –

R6201M6 NOTPLACED –

R6202M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6203M6 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R6204M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6205M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6206M6 0613952R25 CER CHIP RES 100K OHM

5% 0402

R6207M6 0613952R25 CER CHIP RES 100K OHM

5% 0402

R6208M6 0613952Q89 CER CHIP RES 4700 OHM

5 0402

R6209M6 0613952Q89 CER CHIP RES 4700 OHM

5 0402

R620M19 NOTPLACED –

R6210M6 0613952Q89 CER CHIP RES 4700 OHM

5 0402

R6211M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6212M6 NOTPLACED –

R6213M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6214M6 NOTPLACED –

R6215M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6216M6 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R6217M6 0613952Q73 CER CHIP RES 1000 OHM

5 0402

Ref. Des. Part Number Description

R6218M6 0613952Q80 CER CHIP RES 2000 OHM

5 0402

R621M19 NOTPLACED –

R623M19 NOTPLACED –

R624M19 NOTPLACED –

R6301M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6304M6 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R63050M6 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R6305M6 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R6306M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6307M6 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R6310M6 0613952Q37 CER CHIP RES 33.0 OHM 5

0402

R6311M6 0613952Q37 CER CHIP RES 33.0 OHM 5

0402

R6312M6 0613952Q37 CER CHIP RES 33.0 OHM 5

0402

R6313M6 0613952Q37 CER CHIP RES 33.0 OHM 5

0402

R6314M6 0613952Q37 CER CHIP RES 33.0 OHM 5

0402

R6316M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6401M6 0613952R18 CER CHIP RES 51K OHM 5

0402

R6402M6 0613952R32 CER CHIP RES 200K OHM

5 0402

R6403M6 0613952Q81 CER CHIP RES 2200 OHM

5 0402

R6404M6 0613952Q81 CER CHIP RES 2200 OHM

5 0402

R6405M6 0613952Q75 CER CHIP RES 1200 OHM

5 0402

R6406M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

Ref. Des. Part Number Description

R6407M6 0613952Q81 CER CHIP RES 2200 OHM

5 0402

R6409M6 0613952N01 CER CHIP RES 10.0K OHM

1 0402

R6410M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6411M6 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R6414M6 0613952Q61 CER CHIP RES 330 OHM 5

0402

R6415M6 0613952Q61 CER CHIP RES 330 OHM 5

0402

R6416M6 0613952Q61 CER CHIP RES 330 OHM 5

0402

R6417M6 0613952Q61 CER CHIP RES 330 OHM 5

0402

R6419M6 0613952Q37 CER CHIP RES 33.0 OHM 5

0402

R6420M6 0613952R17 CER CHIP RES 47K OHM

5% 0402

R6421M6 0613952R01 CER CHIP RES 10K OHM

5% 0402

R6422M6 0613952Q51 CER CHIP RES 120 OHM 5

0402

R6423M6 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R6424M6 0613952N01 CER CHIP RES 10.0K OHM

1 0402

R6425M6 0613952Q80 CER CHIP RES 2000 OHM

5 0402

R6426M6 0613952Q49 CER CHIP RES 100 OHM 5

0402

R6427M6 0613952R11 CER CHIP RES 27K OHM

5% 0402

R6428M6 0613952R25 CER CHIP RES 100K OHM

5% 0402

R6429M6 0613952R17 CER CHIP RES 47K OHM

5% 0402

R6430M6 0613952R09 CER CHIP RES 22K OHM

5% 0402

Ref. Des. Part Number Description
