Motorola APX 2000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01) 8-317
U6505M6 5189631P01 IC,SYNC STEP-DOWN
CONV
U6506M6 5184790Y04 IC,400MA ADJ VREG
LDO,SOT23
U6507M6 5171682H01 800MA BUCK REGULATOR
U6508M6 51009366001 500MA LOW DROPOUT
CMOS LINEAR REG.
U6509M6 5175114H01 SINGLE AND GATE
MICROPAK
U6510M6 5114007A47 IC,OR,17SZ32,1PER
PKG,SOT-353,PB FREE
U6511M6 5171339H01 MICROPOWER VOLTAGE
REGULATOR
U6601M6 5175114H01 SINGLE AND GATE
MICROPAK
U702M7 5164015H28 IC,TRIDENT,INTEG
SYNTH,RX/TX BSBND
U738M7 5171972L01 SP3T RF SWITCH
U739M7 5103535B53 IC,INVTR,DL,NC7WZ04L6X
,2PER PKG,SC70
U746M7 4805218N63 RF TRANS SOT 323
BFQ67W
VR101M12 4813977M29 DIODE,VREF,MBZ5250,SM,
SOT-23,20V,.225W,ZEN
VR200M12 4813977M29 DIODE,VREF,MBZ5250,SM,
SOT-23,20V,.225W,ZEN
VR3010M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79
VR3011M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79
VR3048M22 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79
VR601M19 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79
VR602M19 4805656W87 DIODE,VCTR, @
15V,1SV279,SOD-523/SC-
79
Y1304M3 48014600001 OSC,TCXO,26.0
Ref. Des. Part Number Description
Y3020M22 48012102005 RESONATOR CERAMIC
1025MHZ
Y3021M22 48012102005 RESONATOR CERAMIC
1025MHZ
Y3053M22 48012102006 RESONATOR CERAMIC
1110MH Z
Y6501M6 4864005H01 RESONATOR, CRYSTAL
24.576 MHZ
Y6502M6 4809995L05 XTAL QUARTZ 32.768KHZ
CC4V-T1
Y6601M6 4802582S85 RESON,QRTZ,12MHZ,TOL
ERANCE10PPM,STABILITY
15PPM,SM,FUND,LO
Y701M7 4871886H01 16.8 MHZ VCTXO .8PPM
Ref. Des. Part Number Description
