8-318 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 700 – 800 MHz (84012266001 / PC000351A01)

700/800 MHz Transceiver (RF) Board Parts List

– PC000351A01

Ref. Des. Part Number Description

C1001M16 2113944M30 CAP,FXD,33PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1002M16 2113944C22 CAP,CHIP,4.7PF,.25PF+/-

,50V-DC,0603,C0G,-55DEG

CMIN,125DEG CMA

C1003M16 2113945C02 CAP,CHIP,.01UF,+10%,-

10%,50V-DC,0603,X7R,-

55DEG CMIN,125DEG CMA

C1004M16 2113944M30 CAP,FXD,33PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1005M16 2113944M30 CAP,FXD,33PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1006M16 2113945C02 CAP,CHIP,.01UF,+10%,-

10%,50V-DC,0603,X7R,-

55DEG CMIN,125DEG CMA

C1007M16 2113944M30 CAP,FXD,33PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1008M16 2113944M30 CAP,FXD,33PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1009M16 2113944M30 CAP,FXD,33PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1010M16 2113945C02 CAP,CHIP,.01UF,+10%,-

10%,50V-DC,0603,X7R,-

55DEG CMIN,125DEG CMA

C1013M16 2113944M21 CAP,FXD,13PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1014M16 NOTPLACED 64AM DUMMY PART NUM-

BER

C1015M16 2113944M30 CAP,FXD,33PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1018M16 2113944M30 CAP,FXD,33PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1019M16 2171741M03 CAP,FXD,18PF,+5%,-

5%,50V-DC,COG,HI Q CAP

C101M12 2113944A31 CAP,CHIP,33PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1020M16 2113944M11 CAP,FXD,5.1PF,.1PF+/-

,50V-DC,0603,C0G,-55DEG

CMIN,125DEG CMAX

C1021M16 2113944M01 CAP,FXD,2PF,.1PF+/-,50V-

DC,0603,C0G,-55DEG

CMIN,125DEG CMAX,PB

C1022M16 2113944M30 CAP,FXD,33PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1023M16 2113944M24 CAP,FXD,18PF,+2%,-

2%,50V-DC,0603,C0G,-

55DEG CMIN,125DEG

CMAX,PB

C1024M16 2113945A12 CAP,CHIP,3300PF,+10%,-

10%,50V-DC,0402,X7R,-

55DEG CMIN,125DEG CM

C1025M16 2113945A12 CAP,CHIP,3300PF,+10%,-

10%,50V-DC,0402,X7R,-

55DEG CMIN,125DEG CM

C1026M16 2113945C07 CAP,CHIP,330PF,+10%,-

10%,50V-DC,0603,X7R,-

55DEG CMIN,125DEG CMA

C1101M11 2113945B02 CAP,CHIP,.01UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1102M11 2188468Y01 CAP,CHIP,1UF,+10%,-

10%,25V-DC,0805,X7R

C1103M11 2113945B02 CAP,CHIP,.01UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

Ref. Des. Part Number Description

C1104M11 NOTPLACED 64AM DUMMY PART NUM-

BER

C1105M11 2113944A19 CAP,CHIP,5.6PF,.5PF+/-

,50V-DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C1106M11 2113945B02 CAP,CHIP,.01UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1107M11 2113944A40 CAP,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX

C1108M11 2113945B02 CAP,CHIP,.01UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1110M11 2113944A31 CAP,CHIP,33PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,P

C1111M11 2113945Y02 CAP:X7R,0402,10%,16V,0.1

C1112M11 2113945B02 CAP,CHIP,.01UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1113M11 2113945B02 CAP,CHIP,.01UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1116M11 2113945Y02 CAP:X7R,0402,10%,16V,0.1

C1117M11 2113945A12 CAP,CHIP,3300PF,+10%,-

10%,50V-DC,0402,X7R,-

55DEG CMIN,125DEG CM

C1118M11 2113945B02 CAP,CHIP,.01UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1119M11 2113945B02 CAP,CHIP,.01UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1120M11 2113945B02 CAP,CHIP,.01UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1122M11 2113944M02 CAP,FXD,2.2PF,.1PF+/-

,50V-DC,0603,C0G,-55DEG

CMIN,125DEG CMAX

Ref. Des. Part Number Description

C1123M11 2113945B02 CAP,CHIP,.01UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1124M11 2113945A13 CAP,CHIP,4700PF,+10%,-

10%,50V-DC,0402,X7R,-

55DEG CMIN,125DEG CM

C1125M11 2113944A21 CAP,CHIP,6.8PF,.5PF+/-

,50V-DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C1126M11 2113945A09 CAP,CHIP,1000PF,+10%,-

10%,50V-DC,0402,X7R,-

55DEG CMIN,125DEG CM

C1127M11 2113945Y02 CAP:X7R,0402,10%,16V,0.1

C1128M11 2113945B02 CAP,CHIP,.01UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1129M11 2113945B02 CAP,CHIP,.01UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1130M11 2113945B02 CAP,CHIP,.01UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1135M11 NOTPLACED 64AM DUMMY PART NUM-

BER

C1137M11 2113945B04 CAP,FXD,.022UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1138M11 2113945B04 CAP,FXD,.022UF,+10%,-

10%,25V-DC,0402,X7R,-

55DEG CMIN,125DEG CMA

C1139M11 2113944A25 CAP,CHIP,10PF,.5PF+/-

,50V-DC,0402,C0G,-55DEG

CMIN,125DEG CMAX

C1140M11 2113945A13 CAP,CHIP,4700PF,+10%,-

10%,50V-DC,0402,X7R,-

55DEG CMIN,125DEG CM

C1141M11 2175793A01 CAP,CHIP,.47UF,+10%,-

10%,6.3V-DC,0402,X5R,-

55DEG CMIN,85DEG CMA

C1142M11 2113945A09 CAP,CHIP,1000PF,+10%,-

10%,50V-DC,0402,X7R,-

55DEG CMIN,125DEG CM

C1155M11 NOTPLACED 64AM DUMMY PART NUM-

BER

Ref. Des. Part Number Description

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
