Motorola APX 2000 Detailed Service Manual

Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 900 MHz (84012478001) 8-379
R6425M6 0613952Q80 CER CHIP RES 2000 OHM
5 0402
R6426M6 0613952Q49 CER CHIP RES 100 OHM 5
0402
R6427M6 0613952R11 CER CHIP RES 27K OHM
5% 0402
R6428M6 0613952R25 CER CHIP RES 100K OHM
5% 0402
R6429M6 0613952R17 CER CHIP RES 47K OHM
5% 0402
R6430M6 0613952R09 CER CHIP RES 22K OHM
5% 0402
R6431M6 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R6432M6 0613952R25 CER CHIP RES 100K OHM
5% 0402
R6433M6 0613952Q32 CER CHIP RES 20.0 OHM 5
0402
R6434M6 0613952Q32 CER CHIP RES 20.0 OHM 5
0402
R6492M6 0613952Q79 CER CHIP RES 1800 OHM
5 0402
R6501M6 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R6502M6 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R6503M6 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R6504M6 0613952R09 CER CHIP RES 22K OHM
5% 0402
R6505M6 0613952Q80 CER CHIP RES 2000 OHM
5 0402
R6506M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6507M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6508M6 0613952R17 CER CHIP RES 47K OHM
5% 0402
R6509M6 0613952R25 CER CHIP RES 100K OHM
5% 0402
Ref. Des. Part Number Description
R6510M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6511M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6512M6 0613952N01 CER CHIP RES 10.0K OHM
1 0402
R6513M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6514M6 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R6515M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6516M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6517M6 0613952Q63 CER CHIP RES 390 OHM 5
0402
R6518M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6519M6 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R6520M6 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R6521M6 0615049H01 KAMAYA 0.2 OHM CHIP
RESISTOR
R6522M6 0613952M66 CER CHIP RES 4750 OHM
1% 0402
R6523M6 0613952R09 CER CHIP RES 22K OHM
5% 0402
R6524M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6525M6 NOTPLACED 64AM DUMMY PART
NUMBER
R6526M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6527M6 0613952N87 CER CHIP RES 78.7K OHM
1 0402
R6528M6 0613952R25 CER CHIP RES 100K OHM
5% 0402
R6529M6 0615049H01 KAMAYA 0.2 OHM CHIP
RESISTOR
Ref. Des. Part Number Description
R6530M6 0613952L30 CER CHIP RES 200 OHM 1
0402
R6531M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6532M6 NOTPLACED 64AM DUMMY PART
NUMBER
R6533M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6534M6 NOTPLACED 64AM DUMMY PART
NUMBER
R6535M6 0613952N01 CER CHIP RES 10.0K OHM
1 0402
R6536M6 0613952Z72 RES,MF,91KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6537M6 0613952P09 CER CHIP RES 121K OHM
1 0402
R6538M6 0613952Q95 CER CHIP RES 8200 OHM
5 0402
R6539M6 0613952P66 CER CHIP RES 475K OHM
1 0402
R6540M6 0613952P66 CER CHIP RES 475K OHM
1 0402
R6541M6 0613952R25 CER CHIP RES 100K OHM
5% 0402
R6542M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6543M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6544M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6545M6 0613952R25 CER CHIP RES 100K OHM
5% 0402
R6546M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6547M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6548M6 NOTPLACED 64AM DUMMY PART
NUMBER
R6550M6 0613952Z64 RES,MF,39KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
Ref. Des. Part Number Description
R6551M6 0613952Z62 RES,MF,33KOHM,1%,.0625
W,SM,0402,200PPM/
CEL,PB-FREE
R6552M6 0613952R25 CER CHIP RES 100K OHM
5% 0402
R6558M6 0613952P22 CER CHIP RES 165K OHM
1 0402
R6561M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6562M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6563M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6564M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6565M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6566M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6567M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6568M6 0613952P47 CER CHIP RES 301K OHM
1 0402
R6570M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6574M6 0613952R25 CER CHIP RES 100K OHM
5% 0402
R6576M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6577M6 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R6578M6 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R6579M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6580M6 0613952R17 CER CHIP RES 47K OHM
5% 0402
R6581M6 0613952Q49 CER CHIP RES 100 OHM 5
0402
R6582M6 0613952Q89 CER CHIP RES 4700 OHM
5 0402
Ref. Des. Part Number Description
