Motorola APX 2000 Detailed Service Manual

8-380 Schematics, Boards Overlays, and Parts Lists: Transceiver (RF) Boards: 900 MHz (84012478001)
R6583M6 0613952R03 CER CHIP RES 12K OHM
5% 0402
R6584M6 0613952Q56 CER CHIP RES 200 OHM 5
0402
R6591M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6592M6 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R6598M6 NOTPLACED 64AM DUMMY PART
NUMBER
R6599M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6601M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6602M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6604M6 0613952Q51 CER CHIP RES 120 OHM 5
0402
R6605M6 0613952Q33 CER CHIP RES 22.0 OHM 5
0402
R6606M6 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R6608M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6609M6 0613952R25 CER CHIP RES 100K OHM
5% 0402
R6616M6 0613952Q80 CER CHIP RES 2000 OHM
5 0402
R6617M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6618M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6619M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R6621M6 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R6622M6 0613952Q35 CER CHIP RES 27.0 OHM 5
0402
R6623M6 0613952Q35 CER CHIP RES 27.0 OHM 5
0402
Ref. Des. Part Number Description
R6624M6 0613952Q35 CER CHIP RES 27.0 OHM 5
0402
R6625M6 0613952Q35 CER CHIP RES 27.0 OHM 5
0402
R6626M6 0613952R01 CER CHIP RES 10K OHM
5% 0402
R698M19 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R699M19 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R701M7 0613952Q64 CER CHIP RES 430 OHM 5
0402
R702M7 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R703M7 0613952Q67 CER CHIP RES 560 OHM 5
0402
R704M7 0613952Q25 CER CHIP RES 10.0 OHM 5
0402
R705M7 0613952Q75 CER CHIP RES 1200 OHM
5 0402
R706M7 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R707M7 0613952Q67 CER CHIP RES 560 OHM 5
0402
R708M7 0613952Q45 CER CHIP RES 68.0 OHM 5
0402
R709M7 NOTPLACED 64AM DUMMY PART
NUMBER
R721M7 0613952R01 CER CHIP RES 10K OHM
5% 0402
R722M7 0613952Q57 CER CHIP RES 220 OHM 5
0402
R723M7 0613952R02 CER CHIP RES 11K OHM 5
0402
R728M7 0613952Q53 CER CHIP RES 150 OHM 5
0402
R729M7 0613952R09 CER CHIP RES 22K OHM
5% 0402
R730M7 0613952Q79 CER CHIP RES 1800 OHM
5 0402
Ref. Des. Part Number Description
R734M7 0613952Q86 CER CHIP RES 3600 OHM
5 0402
R736M7 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R741M7 0613952R09 CER CHIP RES 22K OHM
5% 0402
R742M7 0613952R23 CER CHIP RES 82K OHM
5% 0402
R743M7 0613952R17 CER CHIP RES 47K OHM
5% 0402
R744M7 0613952Q91 CER CHIP RES 5600 OHM
5 0402
R745M7 0613952R09 CER CHIP RES 22K OHM
5% 0402
R746M7 0613952Q12 CER CHIP RES 3.0 OHM 5
0402
R747M7 0613952Q34 CER CHIP RES 24.0 OHM 5
0402
R748M7 0613952Q47 CER CHIP RES 82.0 OHM
5% 0402
R751M7 0613952Q59 CER CHIP RES 270 OHM 5
0402
R754M7 NOTPLACED 64AM DUMMY PART
NUMBER
R757M7 0613952Q59 CER CHIP RES 270 OHM 5
0402
R761M7 0613952Q23 CER CHIP RES 8.2 OHM 5
0402
R762M7 0613952R08 CER CHIP RES 20K OHM 5
0402
R763M7 0613952R19 CER CHIP RES 56K OHM
5% 0402
R766M7 0613952Q92 CER CHIP RES 6200 OHM
5 0402
R769M7 0613952Q34 CER CHIP RES 24.0 OHM 5
0402
R771M7 0613952Q49 CER CHIP RES 100 OHM 5
0402
R776M7 0613952Q67 CER CHIP RES 560 OHM 5
0402
Ref. Des. Part Number Description
R780M7 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R785M7 0613952Q60 CER CHIP RES 300 OHM 5
0402
R799M7 0613952Q60 CER CHIP RES 300 OHM 5
0402
R809M7 0613952Q31 CER CHIP RES 18.0 OHM 5
0402
R822M7 NOTPLACED 64AM DUMMY PART
NUMBER
R823M7 NOTPLACED 64AM DUMMY PART
NUMBER
S2103M2 40012069001 TACT SWITCH,
EMERGENCY
SH1 26012144001 SHIELD, TXOP
SH10 26012156001 SHIELD, MIXER
SH11 26012159001 SHIELD, VCO
SH12 26012152001 SHIELD, GPS/BT
SH13 26012161001 SHIELD, CONTROLLER
SH14 26012143001 SHIELD, MAKO
SH15 26012160001 SHIELD, DRIVER
SH16 26012163001 SHIELD, RXFE
SH17 26012155001 SHIELD, 2ND_LO
SH2 26012154001 SHIELD, ABACUS
SH3 26012149001 SHIELD, ALC
SH4 26012157001 SHIELD, BALUN
SH5 26012153001 SHIELD, FGU
SH6 26012150001 SHIELD, ALC/DC
SH7 26012158001 SHIELD, COUPLER
SH8 26012162001 SHIELD, HF
SH9 26012151001 SHIELD, AUDIO PA
T506M21 2575851B01 RF TRANSFORMER
BALUN
T507M21 2575851B02 RF TRANSFORMER
BALUN
U1001M16 5175143H01 WIDE SUPPLY RANGE OP
AMP
Ref. Des. Part Number Description
