Schematics, Boards Overlays, and Parts Lists: Keypad Board (84012282001) 8-391

PMCN4026B Keypad Board Parts List

Ref. Des. Part Number Description

C2 2113944A40 CAP CER CHP 100.0PF

50V 5%

C4 2113944A40 CAP CER CHP 100.0PF

50V 5%

C6 2113944A40 CAP CER CHP 100.0PF

50V 5%

C7 2113944A40 CAP CER CHP 100.0PF

50V 5%

C8 2113944A40 CAP CER CHP 100.0PF

50V 5%

C9 2113944A40 CAP CER CHP 100.0PF

50V 5%

C10 2113944A40 CAP CER CHP 100.0PF

50V 5%

C11 2113944A40 CAP CER CHP 100.0PF

50V 5%

C12 2113944A40 CAP CER CHP 100.0PF

50V 5%

C13 2113944A40 CAP CER CHP 100.0PF

50V 5%

C14 2113944A40 CAP CER CHP 100.0PF

50V 5%

C15 2113944A40 CAP CER CHP 100.0PF

50V 5%

C16 2113944A40 CAP CER CHP 100.0PF

50V 5%

C17 2113944A40 CAP CER CHP 100.0PF

50V 5%

C18 2113944A40 CAP CER CHP 100.0PF

50V 5%

C19 2113944A40 CAP CER CHP 100.0PF

50V 5%

C20 2113944A40 CAP CER CHP 100.0PF

50V 5%

C21 2113944A40 CAP CER CHP 100.0PF

50V 5%

C22 2113944A40 CAP CER CHP 100.0PF

50V 5%

C23 2113944A40 CAP CER CHP 100.0PF

50V 5%

C24 2113944A40 CAP CER CHP 100.0PF

50V 5%

C25 2113944A40 CAP CER CHP 100.0PF

50V 5%

C26 2113944A40 CAP CER CHP 100.0PF

50V 5%

C27 2113944A40 CAP CER CHP 100.0PF

50V 5%

C28 2113944A40 CAP CER CHP 100.0PF

50V 5%

C29 2113944A40 CAP CER CHP 100.0PF

50V 5%

C30 2113944A40 CAP CER CHP 100.0PF

50V 5%

C31 2113944A40 CAP CER CHP 100.0PF

50V 5%

C2003 2113944A40 CAP CER CHP 100.0PF

50V 5%

C2004 2113944A40 CAP CER CHP 100.0PF

50V 5%

C2005 NOTPLACED –

C2006 NOTPLACED –

C2008 NOTPLACED –

C2009 2113945A05 CAP CER CHP 470PF 50V

10%

C2010 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2011 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2012 2113944A40 CAP CER CHP 100.0PF

50V 5%

C2018 2113946B04 CAP CER CHP 0.10UF

10V 10%

C2020 2113944A26 CAP CER CHP 12.0PF 50V

C2022 2113944A26 CAP CER CHP 12.0PF 50V

Ref. Des. Part Number Description

C2023 2113944A26 CAP CER CHP 12.0PF 50V

C2050 2113946B04 CAP CER CHP 0.10UF

10V 10%

C2051 2113944A40 CAP CER CHP 100.0PF

50V 5%

C2052 2113944A26 CAP CER CHP 12.0PF 50V

C2414M3 2113946D07 CAP,CHIP,4.7UF,+10%,-

10%,6.3V-DC,0603,X5R,-

55DEG CMIN,85DEG CMA

C2415M3 2113945B02 CAP CER CHP 10,000PF

25V 10%

C2416M3 2113946D07 CAP,CHIP,4.7UF,+10%,-

10%,6.3V-DC,0603,X5R,-

55DEG CMIN,85DEG CMA

C2417M3 2171206F01 CAPACITOR, CHIP

MONOLITHIC CERAMIC,

X5R, 4.7UF, 4V, SMD, W18

C2438M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2439M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2440M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2441M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2442M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2443M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

Ref. Des. Part Number Description

C2444M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2445M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2446M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2447M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2448M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2449M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2450M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2451M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2452M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2453M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2454M3 2171051Y01 CAP,FXD,220PF,+1%,-

1%,50V-DC,C0G,-55DEG

CMIN,125DEG CMAX,PB-

C2455M3 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

Ref. Des. Part Number Description

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
