Motorola APX 2000 Detailed Service Manual

8-392 Schematics, Boards Overlays, and Parts Lists: Keypad Board (84012282001)
C2456M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2457M3 2113944A28 CAP CER CHP 18.0PF 50V
5%
C2458M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2459M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2460M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2461M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2462M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2463M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2464M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2465M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
C2466M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2467M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
C2468M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2469M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2470M3 2172180Y01 CAP,CHIP,2.2UF,+20%,-
20%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
C2471M3 2113945A05 CAP CER CHP 470PF 50V
10%
C2472M3 2113945A09 CAP CER CHP 1000PF
50V 10%
C2473M3 2113944A25 CAP CER CHP 10.0PF 50V
+/- 0.5PF
C2474M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2475M3 2113945A09 CAP CER CHP 1000PF
50V 10%
C2477M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2478M3 2113956B54 CAP,FXD,10UF,+20%,-
20%,6.3V-DC,X5R,-55DEG
CMIN,85DEG CMAX,PB-F
C2479M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2480M3 2113956A51 CAP,FXD,1UF,+10%,-
10%,6.3V-DC,0402,X5R,-
55DEG CMIN,85DEG
CMAX,P
C2482M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2483M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
Ref. Des. Part Number Description
C2484M3 2113945Y02 CAP,FXD,.1UF,+10%,-
10%,16V-DC,0402,X7R,-
55DEG CMIN,125DEG
CMAX
C2504M4 2113945A09 CAP CER CHP 1000PF
50V 10%
C2506M4 2113945B02 CAP CER CHP 10,000PF
25V 10%
C2518M4 2113956B33 CAP,FXD,2.2UF,+10%,-
10%,16V-DC,0603,X5R,-
55DEG CMIN,85DEG
CMAX
C2520M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2527M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2528M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2531M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2532M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2534M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2535M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2536M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2538M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2539M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2540M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2541M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2542M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2543M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2544M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
Ref. Des. Part Number Description
C2545M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2546M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2548M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2549M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2550M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2551M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2552M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2553M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2554M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
C2555M4 2113946B04 CAP CER CHP 0.10UF
10V 10%
D1 48009289001 WHITE 2 PIN SIDE FIRE
LED HIGH INT
D2 48009289001 WHITE 2 PIN SIDE FIRE
LED HIGH INT
D3 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D4 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D5 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D6 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D7 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D8 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D9 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
D10 4870359B01 DIODE,SUPR,SM,7.82V,.1
W,ESD PROT,V360
Ref. Des. Part Number Description
