8-402 Schematics, Boards Overlays, and Parts Lists: Keypad Board (84012282001)

PMCN4027A Keypad Board Parts List

Ref. Des. Part Number Description

C2 2113944A40 CAP CER CHP 100.0PF 50V

C4 2113944A40 CAP CER CHP 100.0PF 50V

C6 2113944A40 CAP CER CHP 100.0PF 50V

C7 2113944A40 CAP CER CHP 100.0PF 50V

C8 2113944A40 CAP CER CHP 100.0PF 50V

C9 2113944A40 CAP CER CHP 100.0PF 50V

C10 2113944A40 CAP CER CHP 100.0PF 50V

C11 2113944A40 CAP CER CHP 100.0PF 50V

C12 2113944A40 CAP CER CHP 100.0PF 50V

C13 2113944A40 CAP CER CHP 100.0PF 50V

C14 2113944A40 CAP CER CHP 100.0PF 50V

C15 2113944A40 CAP CER CHP 100.0PF 50V

C16 2113944A40 CAP CER CHP 100.0PF 50V

C17 2113944A40 CAP CER CHP 100.0PF 50V

C18 2113944A40 CAP CER CHP 100.0PF 50V

C19 2113944A40 CAP CER CHP 100.0PF 50V

C20 2113944A40 CAP CER CHP 100.0PF 50V

C21 2113944A40 CAP CER CHP 100.0PF 50V

C22 2113944A40 CAP CER CHP 100.0PF 50V

C23 2113944A40 CAP CER CHP 100.0PF 50V

C24 2113944A40 CAP CER CHP 100.0PF 50V

C25 2113944A40 CAP CER CHP 100.0PF 50V

C26 2113944A40 CAP CER CHP 100.0PF 50V

C27 2113944A40 CAP CER CHP 100.0PF 50V

C28 2113944A40 CAP CER CHP 100.0PF 50V

C29 2113944A40 CAP CER CHP 100.0PF 50V

C30 2113944A40 CAP CER CHP 100.0PF 50V

C31 2113944A40 CAP CER CHP 100.0PF 50V

C2003 2113944A40 CAP CER CHP 100.0PF 50V

C2004 2113944A40 CAP CER CHP 100.0PF 50V

C2005 NOTPLACED –

C2006 NOTPLACED –

C2008 NOTPLACED –

C2009 2113945A05 CAP CER CHP 470PF 50V

10%

C2010 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2011 2113945Y02 CAP,FXD,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG

CMAX

C2012 2113944A40 CAP CER CHP 100.0PF 50V

C2018 2113946B04 CAP CER CHP 0.10UF 10V

10%

C2020 2113944A26 CAP CER CHP 12.0PF 50V

C2022 2113944A26 CAP CER CHP 12.0PF 50V

Ref. Des. Part Number Description

C2023 2113944A26 CAP CER CHP 12.0PF 50V

C2050 2113946B04 CAP CER CHP 0.10UF 10V

10%

C2051 2113944A40 CAP CER CHP 100.0PF 50V

C2052 2113944A26 CAP CER CHP 12.0PF 50V

C2414M3 NOTPLACED –

C2415M3 NOTPLACED –

C2416M3 NOTPLACED –

C2417M3 NOTPLACED –

C2438M3 NOTPLACED –

C2439M3 NOTPLACED –

C2440M3 NOTPLACED –

C2441M3 NOTPLACED –

C2442M3 NOTPLACED –

C2443M3 NOTPLACED –

C2444M3 NOTPLACED –

C2445M3 NOTPLACED –

C2446M3 NOTPLACED –

C2447M3 NOTPLACED –

C2448M3 NOTPLACED –

C2449M3 NOTPLACED –

C2450M3 NOTPLACED –

C2451M3 NOTPLACED –

C2452M3 NOTPLACED –

C2453M3 NOTPLACED –

C2454M4 NOTPLACED –

C2455M3 NOTPLACED –

C2456M3 NOTPLACED –

C2457M3 NOTPLACED –

C2458M3 NOTPLACED –

C2459M3 NOTPLACED –

Ref. Des. Part Number Description

C2460M3 NOTPLACED –

C2461M3 NOTPLACED –

C2462M3 NOTPLACED –

C2463M3 NOTPLACED –

C2464M3 NOTPLACED –

C2465M3 NOTPLACED –

C2466M3 NOTPLACED –

C2467M3 NOTPLACED –

C2468M3 NOTPLACED –

C2469M3 NOTPLACED –

C2470M3 NOTPLACED –

C2471M3 NOTPLACED –

C2472M3 NOTPLACED –

C2473M3 NOTPLACED –

C2474M3 NOTPLACED –

C2475M3 NOTPLACED –

C2477M3 NOTPLACED –

C2478M3 NOTPLACED –

C2479M3 NOTPLACED –

C2480M3 NOTPLACED –

C2482M3 NOTPLACED –

C2483M3 NOTPLACED –

C2484M3 NOTPLACED –

C2504M4 NOTPLACED –

C2506M4 NOTPLACED –

C2518M4 NOTPLACED –

C2520M4 NOTPLACED –

C2527M4 NOTPLACED –

C2528M4 NOTPLACED –

C2531M4 NOTPLACED –

C2532M4 NOTPLACED –

C2534M4 NOTPLACED –

C2535M4 NOTPLACED –

Ref. Des. Part Number Description

Motorola APX 2000 Specifications

General

IP Rating	IP67
Operating Temperature	-30°C to +60°C
GPS	Optional
Bluetooth	No
Frequency Range	700/800 MHz
Power Output	1-5 W (VHF), 1-3 W (700/800 MHz)
Channels	Up to 1, 000
Battery Life	Up to 10 hours (digital)
Digital Protocol	APCO P25
Frequency	VHF: 136-174 MHz, UHF: 380-470 MHz, 700/800 MHz: 764-870 MHz
Power	1-3W (700/800 MHz), 1-5W (VHF)
