Schematics, Boards Overlays, and Parts Lists: Keypad Board (84012282001) 8-403

C2536M4 NOTPLACED –

C2538M4 NOTPLACED –

C2539M4 NOTPLACED –

C2540M4 NOTPLACED –

C2541M4 NOTPLACED –

C2542M4 NOTPLACED –

C2543M4 NOTPLACED –

C2544M4 NOTPLACED –

C2545M4 NOTPLACED –

C2546M4 NOTPLACED –

C2548M4 NOTPLACED –

C2549M4 NOTPLACED –

C2550M4 NOTPLACED –

C2551M4 NOTPLACED –

C2552M4 NOTPLACED –

C2553M4 NOTPLACED –

C2554M4 NOTPLACED –

C2555M4 NOTPLACED –

D1 48009289001 WHITE 2 PIN SIDE FIRE

LED HIGH INT

D2 48009289001 WHITE 2 PIN SIDE FIRE

LED HIGH INT

D3 4870359B01 DIODE,SUPR,SM,7.82V,.1W,

ESD PROT,V360

D4 4870359B01 DIODE,SUPR,SM,7.82V,.1W,

ESD PROT,V360

D5 4870359B01 DIODE,SUPR,SM,7.82V,.1W,

ESD PROT,V360

D6 4870359B01 DIODE,SUPR,SM,7.82V,.1W,

ESD PROT,V360

D7 4870359B01 DIODE,SUPR,SM,7.82V,.1W,

ESD PROT,V360

D8 4870359B01 DIODE,SUPR,SM,7.82V,.1W,

ESD PROT,V360

D9 4870359B01 DIODE,SUPR,SM,7.82V,.1W,

ESD PROT,V360

Ref. Des. Part Number Description

D10 4870359B01 DIODE,SUPR,SM,7.82V,.1W,

ESD PROT,V360

D11 4870359B01 DIODE,SUPR,SM,7.82V,.1W,

ESD PROT,V360

D13 NOTPLACED –

D14 4870359B01 DIODE,SUPR,SM,7.82V,.1W,

ESD PROT,V360

D16 4870359B01 DIODE,SUPR,SM,7.82V,.1W,

ESD PROT,V360

D2521M4 NOTPLACED –

E2001 7685268E01 FERRITE BEAD 20X40 200

MA MAX CHIP

E2002 7685268E01 FERRITE BEAD 20X40 200

MA MAX CHIP

E2003 7685268E01 FERRITE BEAD 20X40 200

MA MAX CHIP

FL1 9171981H01 FILTER 6 CHANNEL EMI

ESD 12PIN

FL2 9171981H01 FILTER 6 CHANNEL EMI

ESD 12PIN

J2002 NOTPLACED –

M2533M4 NOTPLACED –

P1000 0970312N01 CONN,BTB,RCPT,60CONT,.

4MM,GLD,1 STACK HGT

P2000 0970312N01 CONN,BTB,RCPT,60CONT,.

4MM,GLD,1 STACK HGT

P2001 0970312N01 CONN,BTB,RCPT,60CONT,.

4MM,GLD,1 STACK HGT

PCB 84012282001 BOARD, PC , KEYPAD

Q2537M4 NOTPLACED –

Q2547M4 NOTPLACED –

R1 NOTPLACED –

R2 NOTPLACED –

R3 NOTPLACED –

R4 NOTPLACED –

R5 NOTPLACED –

R6 NOTPLACED –

R7 NOTPLACED –

Ref. Des. Part Number Description

R8 NOTPLACED –

R9 NOTPLACED –

R10 NOTPLACED –

R11 NOTPLACED –

R12 NOTPLACED –

R13 NOTPLACED –

R14 NOTPLACED –

R15 NOTPLACED –

R16 0613952Q67 CER CHIP RES 560 OHM 5

0402

R17 NOTPLACED –

R19 0613952Q67 CER CHIP RES 560 OHM 5

0402

R2003 0613952Q53 CER CHIP RES 150 OHM 5

0402

R2004 0613952Q49 CER CHIP RES 100 OHM 5

0402

R2005 0613952Q66 CER CHIP RES 510 OHM 5

0402

R2006 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R2007 0613952Q49 CER CHIP RES 100 OHM 5

0402

R2013 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R2014 0613952R66 CER CHIP RES 0.0 +/-0.050

OHM

R2024 0613952Q09 CER CHIP RES 2.2 OHM 5

0402

R2025 0613952Q09 CER CHIP RES 2.2 OHM 5

0402

R2500 NOTPLACED –

R2502 NOTPLACED –

R2531 NOTPLACED –

R2533 0613952Q82 CER CHIP RES 2400 OHM 5

0402

R2404M3 NOTPLACED –

R2405M3 NOTPLACED –

Ref. Des. Part Number Description

R2406M3 NOTPLACED –

R2407M3 NOTPLACED –

R2408M3 NOTPLACED –

R2412M3 NOTPLACED –

R2414M3 NOTPLACED –

R2416M3 NOTPLACED –

R2418M3 NOTPLACED –

R2419M3 NOTPLACED –

R2433M3 NOTPLACED –

R2434M3 NOTPLACED –

R2435M3 NOTPLACED –

R2436M3 NOTPLACED –

R2437M3 NOTPLACED –

R2441M3 NOTPLACED –

R2442M3 NOTPLACED –

R2443M3 NOTPLACED –

R2444M3 NOTPLACED –

R2449M3 NOTPLACED –

R2450M3 NOTPLACED –

R2451M3 NOTPLACED –

R2452M3 NOTPLACED –

R2453M3 NOTPLACED –

R2454M3 NOTPLACED –

R2455M3 NOTPLACED –

R2456M3 NOTPLACED –

R2457M3 NOTPLACED –

R2458M3 NOTPLACED –

R2459M3 NOTPLACED –

R2460M3 NOTPLACED –

R2461M3 NOTPLACED –

R2465M3 NOTPLACED –

R2466M3 NOTPLACED –

R2467M3 NOTPLACED –

Ref. Des. Part Number Description
