Schematics, Boards Overlays, and Parts Lists: Keypad Lite Board (84012559002) 8-409

PMCN4033A Keypad Lite Board Parts List

Ref. Des. Part Number Description

C2 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C4 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC, 0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C6 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C7 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C8 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C9 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C10 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C11 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C12 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C13 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C14 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C15 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C16 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C17 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C18 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C19 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C20 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C21 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

Ref. Des. Part Number Description

C22 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C24 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C27 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C28 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C2003 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C2004 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C2009 2113945A05 CAPACI-

TOR,CHIP,470PF,+10%,-

10%,50V-DC,0402,X7R,-

55DEG

CMIN,125DEG,CMAX,PB-

FREE

C2010 2113945Y02 CAPACI-

TOR,FIXED,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG,

CMAX,PB-FREE

C2011 2113945Y02 CAPACI-

TOR,FIXED,.1UF,+10%,-

10%,16V-DC,0402,X7R,-

55DEG CMIN,125DEG,

CMAX,PB-FREE

Ref. Des. Part Number Description

C2022 2113944A26 CAPACI-

TOR,CHIP,12PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C2023 2113944A26 CAPACI-

TOR,CHIP,12PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C2050 2113946B04 CAPACI-

TOR,CHIP,.1UF,+10%,-

10%,10V-DC,0402,X5R,-

55DEG CMIN,85DEG

CMAX,PB-FREE

C2051 2113944A40 CAPACI-

TOR,CHIP,100PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

C2052 2113944A26 CAPACI-

TOR,CHIP,12PF,+5%,-

5%,50V-DC,0402,C0G,-

55DEG CMIN,125DEG

CMAX,PB-FREE

D1 4875053H01 DIODE,5V,25A,WHITE LED

0603 19-217 SMD 5V

D2 4875053H01 DIODE,5V,25A,WHITE LED

0603 19-217 SMD 5V

D3 4870359B01 DIODE,SUPPRES-

SOR,SM,7.82V,.1W,ESD

PROTECTION,V360

D4 4870359B01 DIODE,SUPPRES-

SOR,SM,7.82V,.1W,ESD

PROTECTION,V360

D5 4870359B01 DIODE,SUPPRES-

SOR,SM,7.82V,.1W,ESD

PROTECTION,V360

D6 4870359B01 DIODE,SUPPRES-

SOR,SM,7.82V,.1W,ESD

PROTECTION,V360

D7 4870359B01 DIODE,SUPPRES-

SOR,SM,7.82V,.1W,ESD

PROTECTION,V360

D8 4870359B01 DIODE,SUPPRES-

SOR,SM,7.82V,.1W,ESD

PROTECTION,V360

Ref. Des. Part Number Description
