Motorola APX 2000 Detailed Service Manual

8-410 Schematics, Boards Overlays, and Parts Lists: Keypad Lite Board (84012559002)
D9 4870359B01 DIODE,SUPPRESSOR,SM,7
.82V,.1W,ESD
PROTECTION,V360
D10 4870359B01 DIODE,SUPPRESSOR,SM,7
.82V,.1W,ESD
PROTECTION,V360
D11 4870359B01 DIODE,SUPPRESSOR,SM,7
.82V,.1W,ESD
PROTECTION,V360
D13 4870359B01 DIODE,SUPPRESSOR,SM,7
.82V,.1W,ESD
PROTECTION,V360
D14 4870359B01 DIODE,SUPPRESSOR,SM,7
.82V,.1W,ESD
PROTECTION,V360
D16 4870359B01 DIODE,SUPPRESSOR,SM,7
.82V,.1W,ESD
PROTECTION,V360
E1 NOTPLACED 64AM DUMMY PART
NUMBER
E2 NOTPLACED 64AM DUMMY PART
NUMBER
E3 NOTPLACED 64AM DUMMY PART
NUMBER
E4 NOTPLACED 64AM DUMMY PART
NUMBER
E5 NOTPLACED 64AM DUMMY PART
NUMBER
E6 NOTPLACED 64AM DUMMY PART
NUMBER
E7 NOTPLACED 64AM DUMMY PART
NUMBER
E8 NOTPLACED 64AM DUMMY PART
NUMBER
E9 NOTPLACED 64AM DUMMY PART
NUMBER
E10 NOTPLACED 64AM DUMMY PART
NUMBER
E11 NOTPLACED 64AM DUMMY PART
NUMBER
E12 NOTPLACED 64AM DUMMY PART
NUMBER
Ref. Des. Part Number Description
E13 NOTPLACED 64AM DUMMY PART
NUMBER
E14 NOTPLACED 64AM DUMMY PART
NUMBER
E15 NOTPLACED 64AM DUMMY PART
NUMBER
E2001 7685268E01 FILTER,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2002 7685268E01 FILTER,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
E2003 7685268E01 FILTER,FERRITE
BEAD,650MA,SM,0402,CHI
P, 8 0O H M
FL1 9171981H01 EMI FILTER,EMI/RFI,FILTER
6 CHANNEL EMI ESD 12PIN
M1 NOTPLACED 64AM DUMMY PART
NUMBER
M2 NOTPLACED 64AM DUMMY PART
NUMBER
M3 NOTPLACED 64AM DUMMY PART
NUMBER
P1000 0970312N01 CONNECTOR,BOARD TO
BOARD,RECEPTACLE,60C
ONT,.4MM,GOLD,1 STACK
HGT
P2000 0970312N01 CONNECTOR,BOARD TO
BOARD,RECEPTACLE,60C
ONT,.4MM,GOLD,1 STACK
HGT
P2001 9012073001 CONNECTOR,BOARD TO
BOARD,RECEPTACLE,34C
ONT,.4MM,GOLD,STRAIGH
T,CONNECTOR, B2B
RECEPTACLE 34PINS
PASTE 11012015001 SOLDER,PASTE,CARTRIDG
E,SOLDER PASTE - 9.0A,
LOW VOID
PWB 84012559001 PCB,BOARD, PC , LITE
KEYPAD
R16 0613952Q67 RESISTOR,METAL
FILM,560OHM,5%,.0625W,S
M,0402,200PPM/CEL,PB-
FREE
Ref. Des. Part Number Description
R19 0613952Q67 RESISTOR,METAL
FILM,560OHM,5%,.0625W,S
M,0402,200PPM/CEL,PB-
FREE
R2003 0613952Q53 RESISTOR,METAL
FILM,150OHM,5%,.0625W,S
M,0402,200PPM/CEL,PB-
FREE
R2004 0613952Q49 RESISTOR,METAL
FILM,100OHM,5%,.0625W,S
M,0402,200PPM/CEL,PB-
FREE
R2005 0613952Q66 RESISTOR,METAL
FILM,510OHM,5%,.0625W,S
M,0402,200PPM/CEL,PB-
FREE
R2006 0613952R66 RESISTOR,METAL
FILM,0OHM,5%,.0625W,SM,
0402,PB-FREE
R2007 0613952Q49 RESISTOR,METAL
FILM,100OHM,5%,.0625W,S
M,0402,200PPM/CEL,PB-
FREE
R2013 0613952R66 RESISTOR,METAL
FILM,0OHM,5%,.0625W,SM,
0402,PB-FREE
R2014 0613952R66 RESISTOR,METAL
FILM,0OHM,5%,.0625W,SM,
0402,PB-FREE
R2024 0613952Q09 RESISTOR,METAL
FILM,2.2OHM,5%,.0625W,S
M,0402,200PPM/CEL,PB-
FREE
R2025 0613952Q09 RESISTOR,METAL
FILM,3.3KOHM,5%,.0625W,
SM,0402,200PPM/CEL,PB-
FREE
R2531 0613952Q85 RESISTOR,METAL
FILM,10KOHM,5%,.0625W,S
M,0402,200PPM/CEL,PB-
FREE
S19 NOTPLACED 64AM DUMMY PART
NUMBER
S20 NOTPLACED 64AM DUMMY PART
NUMBER
Ref. Des. Part Number Description
S21 NOTPLACED 64AM DUMMY PART
NUMBER
SH1 26012170001 SHIELD,CAN,STEEL,TIN
PLATED,SHIELD, MACE
SH2 26012171001 SHIELD,CAN,STEEL,TIN
PLATED,SHIELD, SDRAM
PWB 84012559002 PCB,BOARD, PC , LITE
KEYPAD
TP2006 NOTPLACED 64AM DUMMY PART
NUMBER
VR1 NOTPLACED 64AM DUMMY PART
NUMBER
Ref. Des. Part Number Description
