Motorola DS4208 Product Reference Guide

Symbologies 9 - 5
Chinese 2 of 5
Chinese 2 of 5 F0h 98h Disable 9-57
Matrix 2 of 5
Matrix 2 of 5 F1h 6Ah Disable 9-58
Matrix 2 of 5 Lengths F1h 6Bh
F1h 6Ch
Length;
Length = 14
9-59
Matrix 2 of 5 Check Digit F1h 6Eh Disable 9-60
Transmit Matrix 2 of 5 Check Digit F1h 6Fh Disable 9-60
Korean 3 of 5
Korean 3 of 5 F1h 45h Disable 9-61
Inverse 1D F1h 4Ah Regular 9-62
Postal Codes
US Postnet 59h Disable 9-63
US Planet 5Ah Disable 9-63
Transmit US Postal Check Digit 5Fh Enable 9-64
UK Postal 5Bh Disable 9-64
Transmit UK Postal Check Digit 60h Enable 9-65
Japan Postal F0h 22h Disable 9-65
Australia Post F0h 23h Disable 9-66
Australia Post Format F1h CEh Autodiscriminate 9-67
Netherlands KIX Code F0h 46h Disable 9-68
USPS 4CB/One Code/Intelligent Mail F1h 50h Disable 9-68
UPU FICS Postal F1h 63h Disable 9-69
GS1 DataBar
GS1 DataBar (GS1 DataBar Omnidirectional, GS1 DataBar
Truncated, GS1 DataBar Stacked,
GS1 DataBar Stacked
Omnidirectional)
F0h 52h Enable 9-70
GS1 DataBar Limited
Non healthcare configurations
Healthcare configuration (DS4208-HC)
F0h 53h
Disable
Enable
9-71
9-71
GS1 DataBar Limited Security Level F1h D8h 3 9-72
Table 9-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
Default
Page
Number

Motorola DS4208 Specifications

General

Connectivity	Wired
Sealing	IP43
Voltage	5 VDC ± 10%
Scan Pattern	Omnidirectional
Interface	USB, RS232, Keyboard Wedge
Decode Capability	1D
Drop Specification	Withstands multiple 6 ft. (1.8 m) drops to concrete
Operating Temperature	32° to 104° F (0° to 40° C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% (non-condensing)
Lighting	Tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting conditions
Power Consumption	2.5 W (typical)
Current	500 mA
Cable Length	6 ft (1.8 m)
