Motorola DS4208 Product Reference Guide

9 - 6 DS4208 Digital Scanner Product Reference Guide
GS1 DataBar Expanded (GS1 DataBar Expanded, GS1
DataBar Expanded Stacked)
F0h 54h Enable 9-73
Convert GS1 DataBar to UPC/EAN F0h 8Dh Disable 9-74
Composite
Composite CC-C
Non healthcare configurations
Healthcare configuration (DS4208-HC)
F0h 55h
Disable
Enable
9-75
9-75
Composite CC-A/B
Non healthcare configurations
Healthcare configuration (DS4208-HC)
F0h 56h
Disable
Enable
9-75
9-75
Composite TLC-39 F0h 73h Disable 9-76
UPC Composite Mode F0h 58h Never Linked 9-76
Composite Beep Mode
Non healthcare configurations
Healthcare configuration (DS4208-HC)
F0h 8Eh
Beep As Each Code
Type is Decoded
Single Beep After
Both are Decoded
9-77
9-77
GS1-128 Emulation Mode for UCC/EAN Composite Codes F0h ABh Disable 9-77
2D Symbologies
PDF417 0Fh Enable 9-78
MicroPDF417 E3h Disable 9-78
Code 128 Emulation 7Bh Disable 9-79
Data Matrix F0h 24h Enable 9-80
Data Matrix Inverse
Non healthcare configurations
Healthcare configuration (DS4208-HC)
F1h 4Ch
Regular
Inverse Autodetect
9-80
9-80
Maxicode F0h 26h Disable 9-81
QR Code F0h 25h Enable 9-81
QR Inverse F1h 4Bh Regular 9-82
MicroQR F1h 3Dh Enable 9-82
Aztec F1h 3Eh Enable 9-83
Aztec Inverse F1h 4Dh Inverse Autodetect 9-83
Table 9-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
Default
Page
Number

Motorola DS4208 Specifications

General

Connectivity	Wired
Sealing	IP43
Voltage	5 VDC ± 10%
Scan Pattern	Omnidirectional
Interface	USB, RS232, Keyboard Wedge
Decode Capability	1D
Drop Specification	Withstands multiple 6 ft. (1.8 m) drops to concrete
Operating Temperature	32° to 104° F (0° to 40° C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% (non-condensing)
Lighting	Tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting conditions
Power Consumption	2.5 W (typical)
Current	500 mA
Cable Length	6 ft (1.8 m)
