A - 2 DS4208 Digital Scanner Product Reference Guide
Decode Mirror Images (Data Matrix Only) F1h 19h Auto 4-16
Mobile Phone/Display Mode F1h CCh Enable in Both Hand-Held and
Hands-Free (Presentation)
Modes
4-17
PDF Prioritization F1h CFh Disable 4-18
PDF Prioritization Timeout F1h D0h 200 ms 4-18
Hand-Held Decode Aiming Pattern F0h 32h Enable 4-19
Hands-Free (Presentation) Decode Aiming
Pattern
F1h 4Eh Enable Hands-Free
(Presentation) Decode Aiming
Pattern on PDF
4-20
Presentation Mode Field of View F1h 61h Full 4-21
Decoding Illumination F0h 2Ah Enable 4-22
Illumination Always On F2h 59h Disable 4-22
Low Light Scene Detection F0h 22A Aiming Dot Low Light Assist
Scene Detection
4-23
Motion Tolerance (Hand-Held Trigger Modes
Only)
F2h 5Ah Disable 4-24
Multicode Mode F1h A5h Disable 4-25
Multicode Expression F1h 95h 1 4-25
Multicode Mode Concatenation F1h CDh Disable 4-31
Multicode Concatenation Symbology F1h D2h Concatenate as PDF417 4-32
Miscellaneous Options
Transmit Code ID Character 2Dh None 4-34
Prefix Value 63h 69h 7013 <CR><LF> 4-35
Suffix 1 Value
Suffix 2 Value
62h 68h
64h 6Ah
7013 <CR><LF> 4-35
Scan Data Transmission Format EBh Data as is 4-36
FN1 Substitution Values 67h 6Dh 7013 <CR> <LF> 4-37
Transmit “No Read” Message 5Eh Disable 4-38
USB Host Parameters
USB Device Type HID Keyboard Emulation 5-5
Symbol Native API (SNAPI) Status
Handshaking
Enable 5-6
Table A-1 Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.

Motorola DS4208 Specifications

General

Connectivity	Wired
Sealing	IP43
Voltage	5 VDC ± 10%
Scan Pattern	Omnidirectional
Interface	USB, RS232, Keyboard Wedge
Decode Capability	1D
Drop Specification	Withstands multiple 6 ft. (1.8 m) drops to concrete
Operating Temperature	32° to 104° F (0° to 40° C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% (non-condensing)
Lighting	Tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting conditions
Power Consumption	2.5 W (typical)
Current	500 mA
Cable Length	6 ft (1.8 m)
