Motorola DS4208 Product Reference Guide

Standard Default Parameters A - 3
USB Country Keyboard Types
(Country Codes)
North American 5-7
USB Keystroke Delay No Delay 5-9
Simulated Caps Lock Disable 5-10
USB CAPS Lock Override Disable 5-10
USB Ignore Unknown Characters Enable 5-11
USB Convert Unknown to Code 39 Disable 5-11
USB Ignore Beep Directive Honor 5-12
USB Ignore Type Directive Honor 5-12
Emulate Keypad Disable 5-13
Emulate Keypad with Leading Zero Disable 5-13
USB Keyboard FN1 Substitution Disable 5-14
Function Key Mapping Disable 5-14
Convert Case No Case Conversion 5-15
USB Static CDC Enable 5-15
USB Polling Interval 8 msec 5-16
Quick Keypad Emulation Disable 5-18
Fast HID Keyboard Disable 5-18
IBM Specification Version Original Specification 5-19
RS-232 Host Parameters
RS-232 Host Types Standard
1
6-6
Baud Rate 9600 6-8
Parity Type None 6-9
Data Bits 8-Bit 6-10
Stop Bits 1 Stop Bit 6-10
Check Receive Errors Enable 6-11
Hardware Handshaking None 6-11
Software Handshaking None 6-13
Host Serial Response Time-out 2 Sec 6-15
RTS Line State Low RTS 6-16
Table A-1 Standard Default Parameters Table (Continued)
Parameter
Parameter
Number
Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.

Motorola DS4208 Specifications

General

Connectivity	Wired
Sealing	IP43
Voltage	5 VDC ± 10%
Scan Pattern	Omnidirectional
Interface	USB, RS232, Keyboard Wedge
Decode Capability	1D
Drop Specification	Withstands multiple 6 ft. (1.8 m) drops to concrete
Operating Temperature	32° to 104° F (0° to 40° C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 95% (non-condensing)
Lighting	Tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting conditions
Power Consumption	2.5 W (typical)
Current	500 mA
Cable Length	6 ft (1.8 m)
