9 - 50 LI2208 Product Reference Guide

Set Length(s) for Discrete 2 of 5 (continued)

D 2 of 5 - One Discrete Length

D 2 of 5 - Two Discrete Lengths

D 2 of 5 - Length Within Range

(1 to 55)

*D 2 of 5 - Any Length

(1 to 55)
