RS-232 INTERFACE
4 - 15
Host Serial Response T
ime-out
This parameter specifies how long
the linear imager waits for an ACK, NAK, ENQ, XON,
or CTS before
determining th
at a transmi
ssion error
occurred.
*
Minimum: 2 sec
Low: 2.5 se
c
Medium: 5 sec
High: 7.5 sec
Maximum: 9.9 sec
76
78
