Motorola LI4278 LINEAR IMAGER Product Reference Guide

A - 4 LI4278 Product Reference Guide
Data Bits (ASCII Format) 8-Bit 7-10
Check Receive Errors Enable 7-10
Hardware Handshaking None 7-12
Software Handshaking None 7-14
Host Serial Response Time-out 2 sec 7-15
RTS Line State Low RTS 7-16
Beep on <BEL> Disable 7-16
Intercharacter Delay 0 msec 7-17
Nixdorf Beep/LED Options Normal Operation 7-18
Ignore Unknown Characters Send Bar Code 7-18
USB Host Parameters
USB Device Type HID Keyboard Emulation 8-5
Symbol Native API (SNAPI) Status Handshaking Enable 8-6
USB Country Keyboard Types (Country Codes) North American 8-7
USB Keystroke Delay No Delay 8-9
USB CAPS Lock Override Disable 8-9
USB Ignore Unknown Characters Send 8-10
USB Convert Unknown to Code 39 Disable 8-10
Emulate Keypad Disable 8-11
Emulate Keypad with Leading Zero Disable 8-12
Quick Keypad Emulation Disable 8-12
USB FN1 Substitution Disable 8-12
Function Key Mapping Disable 8-12
Simulated Caps Lock Disable 8-13
Convert Case No Case Conversion 8-14
USB Static CDC Enable 8-14
Ignore Beep Disable 8-15
Ignore Bar Code Configuration Disable 8-15
USB Polling Interval 8 msec 8-17
IBM 468X/469X Host Parameters
Table A-1 Standard Default Parameters Table (Continued)
Parameter Default
Page
Number
1
User selection is required to configure this interface and this is the most common selection.

Motorola LI4278 LINEAR IMAGER Specifications

General

Scan Rate	547 scans per second
Decode Capability	1D barcodes
Scan Pattern	Single line
Light Source	LED
IP Rating	IP42
Scanner Type	Linear Imager
Battery	Rechargeable Li-ion battery
Drop Specification	1.8 m (6 ft) drops to concrete
Operating Temperature	14°F to 122°F (-10°C to 50°C)
Technology	Linear Imager
Radio Range	Up to 100 m (330 ft) in open air
Interface	USB, RS232, Keyboard Wedge
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% (non-condensing)
Weight	7.9 oz./224 g
Dimensions	9.8 cm H x 7 cm W x 18.6 cm L (3.8 in H x 2.7 in W x 7.3 in L)
