2 - 16 MC65 Integrator Guide
Charging the MC65 Battery
Insert the MC65 into the vehicle cradle to begin charging. A click indicates that the MC65 button release locking
mechanism is enabled and the MC65 is locked in place.
Figure 2-17
MC65 Battery Charging
Removing the MC65
To remove the MC65, press the release levers on the cradle and pull the MC65 up and out of the cradle.
Figure 2-18
Removing the MC65
CAUTION Ensure the MC65 is fully inserted in the cradle. Lack of proper insertion may result in property damage or
personal injury. Motorola, Inc. is not responsible for any loss resulting from the use of the products while
driving.
